ProSoft PTQ-PDPS Quantum PROFIBUS DP Slave Module

Technical Specifications

Model:PTQ-PDPS

Brand:ProSoft

Product type:Schneider Quantum Chassis PROFIBUS DP DPV0 Slave Communication Module

Backplane power:1100mA @5VDC

Communication:1Optically isolated PROFIBUS RS485 DB9 port;1DB9 RS232 debug port

Max baud rate:12MBaud

Cyclic I/O data:244 bytes input,244 bytes output

Weight:0.42kg

Operating temperature:0℃ ~ +60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:Quantum single slot module,250mm104mm40mm

Certification:CE,UL,Class I Division2,PROFIBUS certified

System compatibility

PTQ-PDPS belongs to ProSoft PTQ series in-rack communication module.

It installs into Schneider Quantum PLC chassis,realizes high-speed data exchange with Quantum CPU via Quantum backplane.

It works as PROFIBUS DP slave,allowing Quantum controller to be accessed by external PROFIBUS DP master,such as Siemens S7,ABB PLC and protection IED.

Compatible with Unity Pro,Concept programming software,supports Quantum hot standby HSBY redundant system.

Suitable for petrochemical,water treatment,power station,hybrid multi-brand PLC interconnection renovation and spare replacement.

Function

PROFIBUS DP DPV0 slave module,compliant with IEC61158 standard.

Supports cyclic real-time I/O data exchange,slave diagnosis and alarm information upload.

Comes with standard GSD file for import on PROFIBUS master configuration side.

Internal data buffer maps PROFIBUS DP data to Quantum CPU register area.

ProSoft Configuration Builder software for slave address,input/output data mapping and online diagnostic.

Supports manual rotary switch to set PROFIBUS slave station address.

Bidirectional data exchange between external PROFIBUS DP master and Quantum PAC.

Installation

Insert module into empty slot of Schneider Quantum chassis.

Wire PROFIBUS RS485 bus cable,install terminal resistor at two ends of bus.

Set slave station address via rotary switch on module.

Connect RS232 debug port to PC for parameter configuration and download.

Import GSD file into PROFIBUS master software,configure I/O mapping in Unity Pro or Concept,check LED indicators after power-up.

Interface

1Optical isolated PROFIBUS RS485 DB9 port,1DB9 RS232 debug port,Quantum backplane connector,LED indicators:PWR,FLT,COM,NET.

Feature

Quantum single slot rack-mounted design,hot swappable.

PROFIBUS RS485 with optical isolation,effectively suppress field surge and interference.

Rotary switch for fast station address setting without configuration software.

Supports Quantum hot standby redundant architecture for high reliability control system.

Online point monitoring and diagnostic function for convenient commissioning.

Shock and vibration resistant design,stable operation in industrial cabinet environment.

Diagnostic

Check module power and status LED;communication failure:verify PROFIBUS wiring,bus terminal resistor and baud rate;data abnormal:check GSD file and I/O mapping table.

Product Brief

PTQ-PDPS is ProSoft PTQ series in-chassis PROFIBUS DP slave module for Schneider Quantum PAC.

It converts Quantum PLC into PROFIBUS DP slave station to communicate with third-party PROFIBUS master devices,widely used for multi-brand industrial automation network maintenance and transformation.
