ProSoft RLX2-IFH9E2 RadioLinx Industrial Frequency Hopping Wireless Radio

Technical Specifications

Model:RLX2-IFH9E2

Brand:ProSoft

Product type:RadioLinx 900MHz FHSS Industrial Wireless Ethernet Transceiver

Power supply:10~30VDC

RF frequency:902 ~ 928 MHz

Transmit power:1W

Communication interface:210/100Mbps Ethernet RJ45,RS232 serial port

Encryption:128-bit AES encryption

Weight:0.58kg

Operating temperature:-40℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:125mm90mm*45mm

Certification:CE,UL,FCC,Class I Division2

System compatibility

RLX2-IFH9E2 belongs to ProSoft RadioLinx RLX2 series frequency hopping wireless radio.

It can be configured as master,remote or repeater station,support point-to-point,point-to-multipoint network topology.

Compatible with Rockwell,Schneider,Siemens PLC,SCADA and Ethernet/Modbus TCP field devices.

Backward compatible with legacy RLX-IFH9E radio.

Suitable for oil & gas,water treatment,pipeline,mining remote site long-distance wireless communication renovation and spare replacement.

Function

FHSS frequency hopping anti-interference wireless transmission technology,strong anti-multipath fading ability.

Dual Ethernet port with built-in smart switch,support local device cascading.

128-bit AES data encryption,guarantee secure transmission of industrial control data.

Support master,remote and repeater mode,extend wireless transmission distance via repeater.

ControlScape FH configuration software for network layout,parameter setting and online signal diagnosis.

Built-in SNMP,included OPC server for radio network health monitoring.

Realize transparent wireless bridge for industrial Ethernet and serial data.

Installation

Mount radio module on DIN rail,connect 10~30VDC power supply.

Install matched antenna and lightning protection device according to field distance.

Connect Ethernet cable to PLC/SCADA equipment,serial port for optional serial device access.

Set radio working mode and network ID in ControlScape FH software.

Check RF signal strength and LED indicators after power-on.

Interface

210/100Mbps Ethernet RJ45,1RS232 serial terminal,antenna SMA port,power terminal,LED indicators:PWR,RF,COM,NET.

Feature

DIN rail compact industrial wireless design,wide operating temperature range.

FHSS frequency hopping technology,stable communication under harsh electromagnetic interference environment.

1W high transmit power,long transmission distance up to 30+ miles under line-of-sight condition.

128-bit AES encryption to prevent data tampering and unauthorized access.

Built-in web page and SNMP for remote status monitoring.

Shock and vibration resistant design,suitable for outdoor and harsh industrial cabinet environment.

Diagnostic

Check module power and RF LED;communication failure:check antenna,cable,line of sight and interference;data abnormal:verify network ID,IP address and signal RSSI value.

Product Brief

RLX2-IFH9E2 is ProSoft RadioLinx RLX2 series 900MHz frequency hopping industrial wireless radio.

It provides long-range,high reliability wireless bridge for industrial Ethernet and serial control data,widely used for remote SCADA,oil pipeline and water utility wireless automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
