ProSoft ILX800-SMSG Micro800 GSM SMS Plug-in Module

Technical Specifications

Model:ILX800-SMSG

Brand:ProSoft

Product type:Micro800 SMS Plug-in Communication Module

Power supply:Supplied via Micro800 controller backplane

Communication:GSM cellular network,Bidirectional SMS messaging

Weight:0.06kg

Operating temperature:-40℃ ~ +70℃

Dimension:53mm40mm22mm

Certification:CE,UL,FCC

System compatibility

ILX800-SMSG belongs to ProSoft Micro800 plug-in shturl.cc directly plugs into Allen‑Bradley Micro820,Micro830 and Micro850 controllers,suitable for remote unmanned equipment alarm notification and field status monitoring.

Function

It enables Micro800 PLC to send and receive SMS text messages.Supports equipment fault alarm,production counter,environmental monitoring data sending,phone whitelist function to filter unauthorized incoming messages,pre-built function blocks for CCW programming environment.

Installation

Insert plug-in module into Micro800 controller expansion slot,install SIM card and external GSM antenna,import function block library in Connected Components Workbench,configure SMS trigger logic and authorized phone list,check LED indicators after power on.

Interface

SMA antenna port,Micro800 plug-in edge connector,run and fault status LED indicators.

Feature

Compact small form factor,isolated SMS communication independent from factory IT network,predefined CCW function blocks reduce programming time,supports global GSM network,whitelist security control for message access.

Diagnostic

Check power,signal and fault LED;communication failure:verify SIM card status,antenna connection and GSM signal strength;data abnormal:check SMS trigger logic and whitelist configuration.

Product Brief

ILX800-SMSG is ProSoft Micro800 plug-in SMS module.It adds GSM two-way SMS alarm function for Allen‑Bradley Micro800 PLC,used for remote site equipment warning and status notification in industrial automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and renovation.
