ProSoft ILX56-MM ControlLogix In-Chassis Message Manager Module

Technical Specifications

Model:ILX56-MM

Brand:ProSoft

Product type:ControlLogix In-Chassis Message Manager Module

Power supply:Supplied via ControlLogix 1756 backplane,5V@300mA

Communication:Modbus TCP/IP,EtherNet/IP,DH+,DH485,ControlNet,Siemens Industrial Ethernet

Weight:0.29kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard 1756 single slot module,120mm87mm32mm

Certification:CE,UL

System compatibility

ILX56-MM belongs to ProSoft inRAx shturl.cc is a single-slot module for Rockwell ControlLogix 1756 chassis.It enables data exchange between different controllers including ControlLogix,CompactLogix,PLC5,SLC,MicroLogix,Siemens S7 and Modbus TCP devices,suitable for multi-brand heterogeneous control system integration and upgrade.

Function

It acts as a message manager to realize cross-protocol bidirectional data transmission between up to 16 independent communication interfaces.Supports tag-based data mapping,time or tag-triggered data transfer,web-based configuration without extra software,enables seamless data sharing among different PLC brands.

Installation

Insert module into ControlLogix 1756 chassis backplane,connect Ethernet cable,access built-in web page to configure communication paths and transfer lists,download project via RSLinx Classic,check LED indicators after power-up.

Interface

1*10/100Mbps Ethernet RJ45 port,ControlLogix backplane connector,multi-color LED indicators for module status,network and communication diagnostics.

Feature

Single slot ControlLogix chassis design,supports RIUP hot insertion and removal,web browser configuration,tag browsing function,multiple trigger modes for data transfer,stable operation in industrial cabinet for multi-vendor system interconnection.

Diagnostic

Check module run and fault LED;communication failure:verify Ethernet wiring,IP address and network route;data abnormal:check transfer list,tag mapping and trigger condition settings.

Product Brief

ILX56-MM is ProSoft inRAx message manager module installed in ControlLogix 1756 rack.It bridges multiple heterogeneous automation controllers and network protocols,for industrial multi-brand control system maintenance and data interconnection transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and renovation.
