ProSoft PLX51-DL-232 Industrial Data Logger

Technical Specifications

Model:PLX51-DL-232

Brand:ProSoft

Product type:Industrial Data Logger Module

Power supply:10~28VDC,1.7W

EtherNet/IP:110/100Mbps RJ45,max 10 CIP connections,max 20 TCP connections

Serial port:Isolated RS232,2.5kV isolation

Serial baud rate:1200,2400,4800,9600,19200,38400,57600,115200

Serial protocol:DF1 Full/Half Duplex,Modbus RTU

Error check:BCC,CRC

Storage:Non-volatile memory,support more than 16,777,216 data records

Time resolution:50ms timestamp

Weight:0.37kg

Operating temperature:-20℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:120mm22.5mm*101mm

Certification:CE,UL,Class I Division2

System compatibility

PLX51-DL-232 belongs to ProSoft PLX51 series data logger module.

Read tag data from Rockwell EtherNet/IP Logix controllers,DF1 serial PLC and Modbus RTU field instruments.

Compatible with ControlLogix,CompactLogix,SLC500,PLC-5,MicroLogix.

Suitable for remote unattended station,machinery OEM data collection,process historical data recording,fault trace and spare replacement.

Function

Collect and store process data with UTC timestamp,tag name,data type and value.

Two logging storage modes:stop recording when full or overwrite oldest records.

Supports up to 3 separate Logix controllers for tag reading.

Export stored historical records to CSV file via PLX50 Configuration Utility.

Built-in web server for online status check and diagnostic.

Work under Logix owned mode or standalone mode.

Support DF1 and Modbus RTU serial data source.

All configuration saved in non-volatile memory,retain setting after power off.

Installation

Mount module on DIN rail,connect 10~28VDC power supply and earth terminal.

Connect RJ45 to EtherNet/IP network,connect RS232 terminal to DF1 or Modbus RTU device.

Set serial baud rate,parity and data source via PLX50 Configuration Utility.

Select target PLC tags and configure data logging trigger conditions.

Check LED indicators after power-on.

Interface

110/100Mbps Ethernet RJ45,1isolated RS232 terminal,power & earth terminal,LED indicators:PWR,ERR,COM,NET.

Feature

Thin DIN rail design,save cabinet installation space.

Large non-volatile memory for massive historical data recording.

Isolated RS232 serial port,reduce ground loop interference.

Ideal for remote sites with limited communication bandwidth.

Built-in communication diagnostic function for troubleshooting.

Shock and vibration resistant design,stable long-term operation in industrial cabinet.

Diagnostic

Check PWR and communication LED;communication failure:verify serial wiring,baud rate and parity;data abnormal:check PLC tag access permission and logging trigger setup.

Product Brief

PLX51-DL-232 is ProSoft PLX51 series industrial data logger module.

It collects and stores real-time process data from EtherNet/IP,DF1 or Modbus RTU devices,widely used for remote equipment data recording,failure analysis and production traceability.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and transformation.
