ProSoft PC56-OPC ControlLogix In-Rack PC Module

Technical Specifications

Model:PC56-OPC

Brand:ProSoft

Product type:ControlLogix 1756 Chassis In-Rack Industrial PC with OPC Server

Power supply:Supplied via 1756 backplane

CPU:500MHz

Storage:4GB Compact Flash

OS:Windows XP Professional

Weight:1.0kg

Operating temperature:0℃ ~ +60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:1756 single slot module,132mm104mm89mm

Certification:CE,UL,Class I Division2

System compatibility

PC56-OPC belongs to ProSoft PC56 series in-rack industrial PC.

It plugs directly into Rockwell ControlLogix 1756 rack,communicates with local and remote ControlLogix controllers through ControlBus backplane.

It reads ControlLogix tag data directly and provides OPC data service for upper SCADA,HMI and OPC client software.

Suitable for factory,energy and process control system OPC data gateway renovation and spare replacement.

Function

Integrated OPC Server,directly access ControlLogix tag data over backplane without extra middleware.

Supports redundant deployment with two PC56-OPC modules for fast failover.

Can communicate with multiple local and remote ControlLogix processors via backplane,EtherNet/IP or ControlNet.

Built-in SMC management console for OPC configuration,tag browsing and data monitoring.

Supports standard OPC DA interface for HMI,historian and reporting software data collection.

No need to modify ControlLogix controller ladder logic.

Installation

Insert module into 1756 ControlLogix chassis backplane,connect ethernet cable for OPC client network.

Boot Windows XP system,open SMC console to browse and select ControlLogix tags for OPC server.

Configure OPC access permission and network setting,connect SCADA/HMI OPC client,check module LED indicators after power-up.

Interface

210/100Mbps Ethernet RJ45 ports,1VGA port,2USB ports,1RS232 serial COM port,1756 backplane connector,module power and status LED indicators.

Feature

1756 single slot rack-mounted industrial PC design,fits standard ControlLogix chassis.

Direct backplane high-speed tag access,lower latency compared with external OPC gateway.

Supports hardware redundancy for critical process applications.

Industrial grade compact flash storage,anti-vibration design,stable operation in industrial cabinet environment.

Diagnostic

Check module power and status LED;communication failure:verify backplane connection and ethernet network;OPC data abnormal:check tag permission,SMC configuration and OPC client connection setting.

Product Brief

PC56-OPC is ProSoft PC56 series in-rack industrial PC module for Rockwell ControlLogix 1756 chassis.

It integrates OPC server function,directly reads ControlLogix tag data through backplane and provides OPC DA data service for upper monitoring system,for industrial automation SCADA system maintenance and transformation.
