ProSoft MVI94-DNP FLEX I/O DNP Module

Technical Specifications

Model:MVI94-DNP

Brand:ProSoft

Product type:1794 FLEX I/O In-Chassis DNP3.0 Master/Slave Serial Communication Module

Backplane current:20mA @5VDC

External power:12~24VDC

External current:170mA@24VDC,340mA@12VDC

Communication:DNP3.0 Level2,support partial Level3 function,dual serial ports,RS232/RS422/RS485 jumper selectable

Weight:0.29kg

Operating temperature:0℃ ~ +55℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Dimension:Single slot 1794 module,94mm94mm69mm

Certification:CE,UL,Class I Division2

System compatibility

MVI94-DNP belongs to ProSoft MVI94 series module.

It plugs directly into Rockwell 1794 FLEX I/O rack,compatible with 1794 backplane,data exchange with FLEX controller via backplane I/O mapping.

It enables FLEX I/O system to communicate with DNP3 RTU,IED and SCADA host devices.

Suitable for power substation,water treatment FLEX I/O SCADA system renovation and spare replacement.

Function

Dual independent serial ports,each port configurable as DNP master or slave,support master-slave or slave-slave redundant mode.

Supports DNP unsolicited event reporting,timestamp and SOE sequence of event recording.

Supports binary input,analog input,counter data and user-defined point database.

Master port supports multi-drop polling of DNP field devices.

Internal user-defined register database,asynchronous data exchange between FLEX backplane and DNP network.

Supports radio and modem connection,configurable RTS delay and communication timeout.

Installation

Insert module into 1794 FLEX I/O chassis backplane,wire serial cable for P1/P2 port.

Set RS232/RS422/RS485 interface via jumpers,configure DNP point list in ProSoft Configuration Builder.

Configure FLEX ladder logic and backplane I/O mapping,download project through RSLinx,check LED indicators after power-up.

Interface

2*DB9 serial application ports,debug configuration port,1794 backplane connector,module status,backplane activity,serial activity LED indicators.

Feature

Single slot 1794 chassis design,optical isolation between backplane and serial ports.

Baud rate range from 110 to 115200,flexible point classification and exception reporting.

Text-based diagnostic menu for monitoring DNP point status and communication error statistics.

Co-processor architecture reduces controller scan load,stable operation in power cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify serial wiring,terminal resistance and baud rate;data abnormal:check DNP device address and point mapping table.

Product Brief

MVI94-DNP is ProSoft MVI94 series DNP3 serial communication module for Rockwell 1794 FLEX I/O rack.

It acts as DNP3 serial gateway to realize bidirectional data exchange between FLEX I/O system and DNP3 RTU/IED field devices,for power industrial automation system maintenance and transformation.
