ProSoft MVI69E-LDM CLX LDM Module

Technical Specifications

Model:MVI69E-LDM

Brand:ProSoft

Product type:CompactLogix In-Chassis Linux C/C++ Programmable Development Module

Power supply:Supplied via 1769 backplane,800mA @5VDC

Communication:110/100Mbps Ethernet port,dual isolated serial ports RS232/RS422/RS485 jumper selectable

Memory:64MB SDRAM

Operating System:Linux

Weight:0.29kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard 1769 single slot module,120mm87mm*32mm

Certification:CE,UL

System compatibility

MVI69E-LDM belongs to ProSoft MVI69E series module.

It plugs directly into Rockwell CompactLogix 1769 rack,compatible with 1769 backplane.

It allows users to compile and run custom C/C++ programs,develop private communication drivers and algorithm logic.

Suitable for non-standard protocol conversion,special industrial data processing and customized automation system renovation and spare replacement.

Function

It runs embedded Linux system,supports user C/C++ custom application development.

Built-in dedicated backplane API to realize data exchange with CompactLogix controller.

Independent Ethernet port and dual isolated serial ports can work simultaneously.

Supports custom protocol parsing,data filtering,edge computing and MQTT application development.

Data mapped to CompactLogix controller memory via backplane,flexible register data interaction.

Installation

Insert module into 1769 chassis backplane,connect ethernet or serial cable.

Set serial interface mode via jumpers,compile and download custom Linux application program.

Configure module parameters in ProSoft Configuration Builder,download project through RSLinx,check LED indicators after power-up.

Interface

110/100Mbps Ethernet RJ45 port,2RJ45 serial application ports,1*debug port,1769 backplane connector,module status,network and serial activity LED indicators.

Feature

Single slot 1769 chassis design,fanless industrial design.

Serial ports with isolation protection,auto crossover ethernet detection.

Complete Linux development toolkit,Eclipse IDE and sample source code provided.

Supports custom TCP/UDP socket programming,stable operation in industrial cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify ethernet/serial wiring,IP address and baud rate;data abnormal:check custom application program and backplane data mapping.

Product Brief

MVI69E-LDM is ProSoft MVI69E series Linux programmable development module for CompactLogix rack.

It provides embedded Linux runtime environment for custom C/C++ program development,realizing special protocol conversion and algorithm processing with CompactLogix,for industrial automation system maintenance and transformation.
