ProSoft MVI56-S3964R CLX S3964R Module

Technical Specifications

Model:MVI56-S3964R

Brand:ProSoft

Product type:ControlLogix In-Chassis Siemens 3964R Serial Communication Module

Power supply:Supplied via 1756 backplane,800mA @5.1VDC,3mA @24VDC

Communication:Siemens 3964R / RK512,dual serial ports,RS232/RS422

Weight:0.29kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard 1756 single slot module,120mm87mm32mm

Certification:CE,UL

System compatibility

MVI56-S3964R belongs to ProSoft MVI56 series module.

It plugs directly into Rockwell ControlLogix 1756 rack,compatible with ControlLogix PAC controllers.

It realizes point-to-point communication between ControlLogix and Siemens devices supporting 3964R or RK512 protocol.

Suitable for old Siemens PLC system renovation and spare replacement.

Function

It supports 3964R protocol with or without RK512 function,two serial ports work independently.

Supports DB-SEND and DB-FETCH instruction,max 512 bytes single transmission data.

Built-in BCC checksum to guarantee data transmission integrity,supports configurable byte swap.

Data mapped to ControlLogix controller memory via backplane,supports baud rate from 300 to 115200.

Installation

Insert module into ControlLogix chassis backplane,wire serial cable.

Set RS232 or RS422 interface mode via jumpers,configure serial parameters in ProSoft Configuration Builder.

Import AOI into Studio5000,download project through RSLinx,check LED indicators after power-up.

Interface

2RJ45 serial application ports,1RJ45 CFG RS232 configuration port,1756 backplane connector,module status,backplane transfer and serial activity LED indicators.

Feature

Single slot 1756 chassis design,500V optical isolation between backplane and serial ports.

Supports full hardware handshake,modem and multi-drop connection.

Configurable timeout and retry parameters,stable operation in industrial cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify serial wiring,baud rate and parity;data abnormal:check protocol mode and byte swap configuration.

Product Brief

MVI56-S3964R is ProSoft MVI56 series Siemens 3964R serial communication module for ControlLogix rack.

It enables point-to-point bidirectional serial data exchange between ControlLogix PAC and legacy Siemens 3964R/RK512 equipment,for industrial automation system maintenance and transformation.
