ProSoft MVI46-MBP SLC500 MBP Module

Technical Specifications

Model:MVI46-MBP

Brand:ProSoft

Product type:SLC500 In-Chassis Modbus Plus Communication Module

Power supply:Supplied via SLC500 backplane,800mA @5VDC

Communication:Modbus Plus

Weight:0.27kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard SLC500 single slot module,120mm87mm32mm

Certification:CE,UL

System compatibility

MVI46-MBP belongs to ProSoft MVI46 series module.It plugs directly into Rockwell SLC500 rack,compatible with SLC 5/02 and above processors with M0/M1 file capability,suitable for connecting SLC500 to Modbus Plus network and legacy Modicon PLC system renovation and spare replacement.

Function

It works as Modbus Plus peer node,supports master and slave mode,realizes bidirectional data exchange between SLC500 and Modbus Plus devices.The module has 4000 words internal register space for data interaction,data mapped to SLC500 controller memory via backplane.

Installation

Insert module into SLC500 chassis backplane,connect Modbus Plus bus cable,set Modbus Plus node address and configure data mapping via ProSoft Configuration Builder,download project through RSLinx,check LED indicators after power-up.

Interface

Modbus Plus network port,RJ45 configuration serial port,SLC500 backplane connector,module status,network and communication LED indicators.

Feature

Single slot SLC500 chassis design,peer-to-peer Modbus Plus communication,large internal register database,web diagnostic interface,stable operation in industrial cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify Modbus Plus bus cable,node address and network termination;data abnormal:check module parameter configuration and data mapping table.

Product Brief

MVI46-MBP is ProSoft MVI46 series Modbus Plus communication module for SLC500 rack.It connects Rockwell SLC500 controller to Modbus Plus network and Modicon controllers,for industrial automation system maintenance and transformation.
