ProSoft 5201-MNET-101S Modbus TCP to IEC 101 Slave Gateway

Technical Specifications

Model:5201-MNET-101S

Brand:ProSoft

Product type:Protocol Communication Gateway

Power supply:18-32VDC

Communication:Modbus TCP Client/Server,IEC 60870-5-101 Slave(RS232/422/485)

Weight:0.34kg

Operating temperature:-40℃ ~ +70℃

Dimension:125mm86mm35mm

Certification:CE,UL

System compatibility

5201-MNET-101S belongs to ProLinx series DIN rail gateway.It connects Modbus TCP control network and IEC101 master telecontrol equipment,widely used in power substation automation renovation and spare replacement.

Function

It acts as Modbus TCP client/server and IEC101 slave,realizes bidirectional real-time data mapping between Modbus TCP PLC system and IEC101 master monitoring host for power telecontrol data transmission.

Installation

DIN rail mounting,connect 24VDC power,wire Ethernet and IEC101 serial bus,set serial parameters and point mapping via configuration software,check LED indicators.

Interface

1*10/100Mbps Ethernet port,configurable IEC101 serial terminal,power terminal,run and fault status LED indicators.

Feature

Compact DIN rail housing,support power industry IEC101 telecontrol protocol,configurable serial physical interface,anti-interference for substation harsh electromagnetic environment.

Diagnostic

Check power,link and fault LED;communication failure:verify network cable,serial wiring,baud rate and address;data abnormal:check telemetry and remote signal point mapping table.

Product Brief

5201-MNET-101S is ProSoft ProLinx protocol gateway,bridge Modbus TCP network and IEC101 master telecontrol equipment,for power substation automation maintenance and system transformation.
