ProSoft 3170-PDP PROFIBUS DP Communication Adapter

Technical Specifications

Model:3170-PDP

Brand:ProSoft

Product type:PROFIBUS DP Communication Adapter

Power supply:12-24VDC

Communication:PROFIBUS DP,RS485

Max I/O modules:8

Weight:0.24kg

Operating temperature:-40℃ ~ +85℃

Dimension:101.6mm71.1mm30.5mm

Certification:CE,UL

System compatibility

3170-PDP is ProSoft communication adapter,designed for Rockwell FLEX I/O system.It connects FLEX I/O modules to PROFIBUS DP master devices for data acquisition and control,widely used in industrial automation renovation and maintenance.

Function

3170-PDP acts as PROFIBUS DP slave,realizes bidirectional data exchange between FLEX I/O and PROFIBUS DP host system.Supports discrete and analog data access,uses rotary switch for station address setting.

Installation

Install on FLEX I/O rack,wire PROFIBUS DP bus,set rotary switch for station address,check LED indicators after power on.

Interface

PROFIBUS DP RS485 terminal,status LED indicators,module bus connector for FLEX rack.

Feature

Compact single slot design,wide temperature range,supports PROFIBUS DPV0/DPV1,stable performance for harsh industrial environments.

Diagnostic

Check power LED and communication LED;No communication:verify station address,baud rate and bus wiring;Data abnormal:check I/O module status and GSD configuration.

Product Brief

3170-PDP is ProSoft PROFIBUS DP slave adapter for FLEX I/O rack.It enables FLEX I/O to communicate with PROFIBUS DP master equipment,used for industrial system spare replacement and maintenance.
