HIMA F6213 Safety Digital Input Module

Technical Specifications

Model:F6213

Brand:HIMA

Safety certification:SIL3,IEC61508,TÜV certified

Channel:16-channel safety digital input

Input:24V DC,dry contact or PNP/NPN signal

Diagnosis:Per channel wire break and short circuit loop monitoring

Mounting:Plug-in subrack installation

Protection class:IP20

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.37kg

Certification:CE

System compatibility

Designed for HIMA HIQuad X safety system,used to collect field switch and sensor signals,widely used in petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function

SIL3 16-channel safety digital input module.It acquires digital status signals from field limit switches,pressure switches and safety sensors,and transmits data to HIQuad X safety controller.Each channel supports independent loop fault monitoring.When wire break or short circuit is detected,the module sends fault alarm.

Installation

Plug into HIQuad X rack backplane,wire field sensors to module terminals,configure via SILworX engineering software.

Interface

‑16 channels signal input terminals

‑Backplane safety bus connector

‑LED indicators for channel status and fault

Circuit feature

1oo2 fail-safe safety architecture,periodic hardware self-test,strong anti-electromagnetic interference,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature

HIQuad X series SIL3 16-channel digital input module F6213. Common faults:input channel damage,terminal connector failure,backplane contact failure.Confirm rack compatibility before replacement.

Diagnostic

Module or wiring fault triggers channel fault alarm;controller executes safety interlock logic.

Built‑in function

F6213 collects field digital status signals for SIS safety instrumented system emergency shutdown protection,widely used for process plant safety spare replacement.

Product Brief

F6213 belongs to HIMA HIQuad X family,plug-in SIL3 16-channel digital input module for HIQuad X safety subrack. Verify rack compatibility before ordering. Test signal acquisition and fault diagnosis function during commissioning. ESD anti‑static protection shall be followed during installation.
