HIMA F6208 Safety Analog Input Module

Technical Specifications

Model:F6208

Brand:HIMA

Safety certification:SIL3,IEC61508,TÜV certified

Channel:8-channel analog input

Input signal:4~20mA,2-wire transmitter supply

Diagnosis:Per channel wire break,short circuit and transmitter fault monitoring

Mounting:Plug-in subrack installation

Protection class:IP20

Power supply:24V DC

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.41kg

Certification:CE

System compatibility

Designed for HIMA HIQuad X safety system,collects analog signals from pressure,temperature and flow transmitters,widely used in petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function

SIL3 8-channel safety analog input module.It acquires 4-20mA analog field measurement signals and transmits data to HIQuad X safety controller.Each channel supports independent loop fault monitoring.When wire break,short circuit or transmitter failure detected,the module triggers fault alarm.

Installation

Plug into HIQuad X rack backplane,wire field transmitters to module terminals,configure via SILworX engineering software.

Interface

‑8 channels analog signal input terminals

‑Backplane safety bus connector

‑LED indicators for channel,communication and fault status

Circuit feature

1oo2 fail-safe safety architecture,periodic hardware self-test,strong anti-electromagnetic interference,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature

HIQuad X series SIL3 8-channel analog input module F6208. Common faults:input channel damage,terminal connector failure,backplane contact failure.Confirm rack compatibility before replacement.

Diagnostic

Module or wiring fault triggers channel fault alarm;controller executes safety interlock logic.

Built‑in function

F6208 collects field analog measurement signals for SIS safety instrumented system emergency shutdown protection,widely used for process plant safety spare replacement.

Product Brief

F6208 belongs to HIMA HIQuad X family,plug-in SIL3 8-channel analog input module for HIQuad X safety subrack. Verify rack compatibility before ordering.Test analog signal acquisition and fault diagnosis function during commissioning. ESD anti‑static protection shall be followed during installation.
