ProSoft PS-QS-1x10-0781 QuickServer Gateway

Technical Specifications

Model:PS-QS-1x10-0781

Brand:ProSoft

Product type:Standalone QuickServer EtherNet/IP to BACnet IP / BACnet MS/TP Protocol Gateway

Power supply:9~30VDC / VAC

Communication:110/100Mbps Ethernet RJ45;2RS485 terminal ports for BACnet MS/TP

Data point capacity:250 points

Weight:0.34kg

Operating temperature:0℃ ~ +60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~90%,non-condensing

Dimension:120mm45mm110mm

Certification:CE,UL,BTL certified

System compatibility

PS-QS-1x10-0781 belongs to ProSoft QuickServer series standalone protocol gateway.

It communicates with Rockwell ControlLogix,CompactLogix controllers via EtherNet/IP network.

It connects BACnet building automation devices including HVAC controllers,air handling units,temperature sensors via BACnet IP or BACnet MS/TP.

Suitable for industrial and building automation mixed network,HVAC system renovation and spare replacement.

Function

Realize bidirectional protocol conversion between EtherNet/IP and BACnet IP / BACnet MS/TP.

Supports BACnet COV function to reduce network data traffic.

DIP switch for quick baud rate and node address setting.

Built-in web server for configuration,data monitoring and diagnostic.

Use FieldServer Toolbox software for offline configuration and point mapping.

Supports custom configuration preset before delivery.

Bidirectional data exchange between Rockwell PLC and BACnet building automation field devices.

Installation

Mount gateway on DIN rail,connect 9~30V power supply.

Connect Ethernet cable to EtherNet/IP network,wire RS485 terminals for BACnet MS/TP bus.

Set bus parameters by DIP switches,configure point mapping in FieldServer Toolbox.

Access web page to verify communication,check LED indicators after power-up.

Interface

110/100Mbps Ethernet RJ45 port,2RS485 terminal blocks,power terminal,LED indicators:PWR,FLT,COM,NET.

Feature

DIN rail compact standalone QuickServer design for building automation.

BTL certified BACnet protocol implementation,stable for HVAC control.

DIP switch for fast on-site parameter setting without PC.

Web-based diagnostic interface for easy commissioning and troubleshooting.

Shock and vibration resistant design,stable operation in automation cabinet environment.

Diagnostic

Check module power and status LED;communication failure:verify ethernet wiring,IP address and RS485 bus terminal resistor;data abnormal:check BACnet object and point mapping table.

Product Brief

PS-QS-1x10-0781 is ProSoft QuickServer series protocol gateway.

It completes bidirectional data conversion between EtherNet/IP industrial control network and BACnet building automation network,widely used for HVAC and building control system maintenance and transformation.
