ProSoft MVI56-AFC CLX AFC Module

Technical Specifications

Model:MVI56-AFC

Brand:ProSoft

Product type:ControlLogix In-Chassis Flow Computer Module

Power supply:Supplied via 1756 backplane,800mA @5.1VDC,3mA @24VDC

Communication:Modbus TCP,RS232/RS422/RS485 serial

Weight:0.29kg

Operating temperature:0℃ ~ +60℃

Dimension:Standard 1756 single slot module,120mm87mm32mm

Certification:CE,UL,ATEX

System compatibility

MVI56-AFC belongs to ProSoft MVI56 series module.It plugs directly into Rockwell ControlLogix 1756 rack,works as co-processor for flow calculation,suitable for oil & gas pipeline custody transfer,liquid and gas metering system upgrade and spare replacement.

Function

It performs gas and liquid flow calculation complying with AGA and API industry standards,supports up to 16 meter runs for flow measurement.Records hourly/daily historical archive and event audit log,realizes bidirectional data exchange with ControlLogix controller via backplane,supports Modbus TCP and serial interface for remote configuration and diagnostics.

Installation

Insert module into ControlLogix chassis backplane,connect Ethernet and serial field wiring,configure meter parameters via AFC Manager software,import AOI instructions into Studio5000,download project through RSLinx,check LED indicators after power-up.

Interface

110/100Mbps Ethernet RJ45 port,2RJ45 serial application ports,1756 backplane connector,alpha-numeric display,module status,network and application LED indicators.

Feature

Single slot 1756 chassis design,built-in custody transfer calculation algorithm,non-volatile memory for data archiving,audit trail for data verification,galvanic isolated serial ports,stable operation in oil & gas cabinet environment.

Diagnostic

Check module run and fault LED;communication failure:verify Ethernet/serial wiring,IP address and baud rate;data abnormal:check meter configuration and flow calculation parameter setting.

Product Brief

MVI56-AFC is ProSoft MVI56 series flow computer module for ControlLogix rack.It provides industry standard gas and liquid flow computation for oil and gas metering applications,for industrial automation system maintenance and transformation.

Disclaimer

Product parameters are for reference only and shall not be used as pricing basis. Goods are in short supply and will be powered on for inspection before shipment. Overseas delivery lead time is 3-7 working days. The product is only used for equipment maintenance and renovation.
