ProSoft AN-X-TI EtherNet/IP to TI 505 Remote I/O Master Gateway

Technical Specifications

Model:AN-X-TI

Brand:ProSoft

Product type:Protocol Communication Gateway

Power supply:18-32VDC

Communication:EtherNet/IP, Texas Instruments TI505 Remote I/O

Weight:0.35kg

Operating temperature:-40℃ ~ +70℃

Dimension:127mm102mm35mm

Certification:CE,UL

System compatibility

AN-X-TI belongs to ProSoft AN-X series DIN rail gateway.It connects modern EtherNet/IP control network with legacy TI505 Remote I/O racks,suitable for obsolete Texas Instruments automation system upgrade and spare replacement.

Function

It acts as TI505 Remote I/O master device,realizes bidirectional real-time I/O data mapping between EtherNet/IP controller and TI505 Remote I/O bases,supports automatic scan list generation and RSLogix5000 tag creation for system migration.

Installation

DIN rail mounting,connect 24VDC power,wire Ethernet and TI505 Remote I/O bus,configure rack parameters and data mapping via built-in web page,check LED indicators.

Interface

1*10/100Mbps Ethernet RJ45 port,TI Remote I/O bus terminal,power terminal,run and fault status LED indicators.

Feature

Compact DIN rail housing,supports up to 15 remote I/O bases,web browser configuration without special software,firmware upgradable over Ethernet,low-risk phased system upgrade.

Diagnostic

Check power,link and fault LED;communication failure:verify network cable,bus wiring,station address and baud rate;data abnormal:check I/O mapping and web configuration.

Product Brief

AN-X-TI is ProSoft AN-X series protocol gateway,bridge EtherNet/IP network and legacy Texas Instruments TI505 Remote I/O racks,for old industrial automation system maintenance and transformation.
