ProSoft 5201-DFNT-DNPM EtherNet/IP to DeviceNet Master Gateway

Technical Specifications

Model:5201-DFNT-DNPM

Brand:ProSoft

Product type:Protocol Communication Gateway

Power supply:10-36VDC

Communication:EtherNet/IP Client/Server,DeviceNet Master

Weight:0.34kg

Operating temperature:-40℃ ~ +70℃

Dimension:125mm86mm35mm

Certification:CE,UL

System compatibility

5201-DFNT-DNPM belongs to ProLinx series DIN rail gateway.It links Rockwell EtherNet/IP control network with DeviceNet slave field devices,suitable for factory automation upgrade and spare replacement.

Function

It acts as EtherNet/IP client/server and DeviceNet master,realizes bidirectional real-time data mapping between EtherNet/IP PLC system and DeviceNet field I/O,valves and sensors.

Installation

DIN rail mounting,connect 24VDC power,wire Ethernet and DeviceNet bus cable,set node address and data mapping via configuration software,check LED indicators.

Interface

1*10/100Mbps Ethernet port,DeviceNet terminal port,power terminal,run and fault status LED indicators.

Feature

Compact DIN rail housing,support multi-node DeviceNet bus,scan DeviceNet slave devices automatically,stable performance for harsh industrial field environment.

Diagnostic

Check power,link and fault LED;communication failure:verify network cable,DeviceNet bus terminal resistor,node address and baud rate;data abnormal:check device mapping list.

Product Brief

5201-DFNT-DNPM is ProSoft ProLinx protocol gateway,bridge EtherNet/IP network and DeviceNet slave devices,used for industrial automation system maintenance and transformation.
