OPTIMATION P-MC06B-2-SSE Vacuum Suction Cup Assembly

Module Feature

P-MC06B-2-SSE is industrial bellows type vacuum suction cup assembly. Designed for semiconductor wet bench thin wafer and substrate transfer. Bellows structure provides small buffer stroke to compensate height difference and absorb contact shock during pick-up. 6mm suction cup diameter. Material features excellent resistance against wet bench dilute acid, alkali and solvent chemicals. Built-in internal fitting with SSE connector interface. Widely used in wafer transfer end effector of wet process and chemical delivery equipment.

Working principle: Negative vacuum pressure enters the suction cup chamber. The bellows cup fits closely against wafer surface to hold substrate securely. Vacuum release will separate the cup from workpiece. The flexible bellows reduces impact force and tolerates minor parallelism deviation. Onboard components:Bellows suction cup body, built-in connector fitting, vacuum air passage

LED indicatorsNo LED indicators, passive pneumatic component

Hardware self-diagnosis

Visual inspection for cracks, aging and surface damage, vacuum leak test, connector sealing check

Programming softwareNo configuration software required, mechanical pneumatic accessory

Electrical & Process ParametersNo electrical parts, driven by vacuum generator

Mechanical & Structure

Cup diameter:6mm Cup type:Bellows style Interface:SSE quick connector Material:Chemical resistant elastomer Mounting:Quick connect installation on vacuum gripper Protection class:IP65

Environmental

Operating temperature:0℃ ~ +60℃ Ambient humidity:5~95% non-condensing Chemical resistance:Resist common wet bench process chemicals Status:Industrial vacuum suction cup assembly

System compatibility

Compatible with vacuum generators, pneumatic solenoid valves and wafer handling robot end effector for wet bench automation.

Function

P-MC06B-2-SSE vacuum suction cup for picking and releasing thin semiconductor wafers. Cup aging, crack or contamination will cause vacuum leakage leading to dropping workpiece. It is pneumatic end effector accessory for wet bench wafer transfer automation.

Installation

Follow lockout/tagout safety procedure before installation. Cut off vacuum air supply. Insert the SSE quick connector into gripper vacuum port. Complete vacuum pipeline connection and run leak test before wafer handling operation.

InterfaceSSE quick connect interface and internal vacuum air passage.

Diagnostic

Vacuum leak:Suction cup cracked, worn, or connector not fully locked. Fail to grip workpiece:Insufficient vacuum pressure or contaminated cup contact surface. Permanent bellows deformation:Long term chemical corrosion or over compression.

Product Brief

P-MC06B-2-SSE bellows vacuum suction cup assembly,6mm diameter,chemical resistant elastomer with SSE quick connector,for semiconductor wet bench wafer pick and place handling.
