OPTIMATION 4-SLOT RTU Chassis

Module Feature

OPTIMATION 4-SLOT is OptiLogic series 4-slot modular RTU chassis (OL4054 base frame). Designed to accept full range OptiLogic hot-pluggable I/O cards. Built-in backplane bus supplies power and data communication to each slot. Unused slots can be equipped with OL0001 blank filler cards to preserve internal airflow and EMC shielding. DIN rail mounting for electrical cabinet installation. Widely used in semiconductor wet bench and chemical delivery control cabinet for distributed I/O signal collection and control.

Working principle: The internal backplane provides 5V power supply and parallel data bus for all inserted I/O modules. All module data is transmitted to the main controller. Empty slots without filler card will reduce heat dissipation and introduce electromagnetic interference. Onboard components:Metal housing, internal backplane PCB, card slot edge connectors, front status LED mounting position, DC power terminal block

LED indicatorsLED indicators located on front panel of matching OL4054 mainboard.

Hardware self-diagnosis

Visual inspection of backplane connectors, check for bent pins, continuity test of backplane bus, mechanical fit test with OptiLogic modules.

Programming software

OPTIMATION OL System Builder software for module recognition and system configuration.

Electrical & Process Parameters

Backplane:4 slots Mounting:DIN rail Protection class:IP20 Power supply:Power fed by OL4054 mainboard

Mechanical & Structure

Mounting:Cabinet DIN rail installation Material:Metal housing Protection class:IP20

Environmental

Operating temperature:0℃ ~ +50℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status:OPTIMATION OptiLogic 4 slot RTU chassis

System compatibility

Compatible with OL4054 mainboard, all OptiLogic I/O modules and OL0001 blank filler card.

Function

4-SLOT chassis manufactured by OPTIMATION. It serves as mechanical and electrical carrier for OptiLogic I/O modules. Bent backplane pins will cause module recognition failure. It is rack base accessory for wet bench automation distributed control system.

Installation

Follow lockout/tagout safety procedure before installation. Power off system. Mount chassis on DIN rail, insert mainboard and I/O modules, install OL0001 filler cards on vacant slots. Lock all modules securely.

InterfaceBackplane edge connectors for I/O modules, power terminal interface for mainboard.

Diagnostic

Module cannot be detected:Backplane pin bent or contaminated. Poor contact:Module latch not locked or backplane dust contamination. Short circuit:Backplane insulation damage.

Product Brief

4-SLOT OPTIMATION OptiLogic 4-slot RTU chassis,DIN rail mount modular rack base,works with OL4054 mainboard and OptiLogic I/O modules,for semiconductor wet bench and chemical delivery control cabinet distributed I/O system.
