HIMA Z7138/3330/C5 Digital Output Module

Technical Specifications

Model:Z7138/3330/C5

Brand:HIMA

Safety certification:SIL3,IEC61508

Power supply:24V DC

Output channels:8 digital safety output channels

Per channel output current:0.5A continuous

Diagnosis:Channel output readback monitoring,short-circuit detection,per-channel fault diagnosis

Mounting:35mm standard DIN rail installation

Protection class:IP20

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.38kg

Certification:CE

System compatibility

Designed for HIMA HIQuad X PES safety system,used to drive field solenoid valves and safety actuators,widely used in petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function

SIL3 8-channel digital safety output module equipped with 3330/C5 connector assembly.It receives safety control commands from HIQuad X safety controller and outputs 24V DC signal to field actuators and solenoid valves.Each channel has independent readback circuit to verify actual output status.Short-circuit and channel failure will trigger fault alarm and send diagnostic data to safety controller.

Installation

Clip onto standard 35mm DIN rail in control cabinet,complete field actuator wiring via 3330/C5 connector,configure channel parameters via SILworX engineering software.

Interface

‑Field signal wiring connector(3330/C5)

‑Internal safety bus connector

‑LED indicators for channel run and fault status

Circuit feature

Fail-safe safety output design,permanent channel readback diagnosis,short-circuit protection,galvanic isolation,strong anti-electromagnetic interference,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature

HIQuad X series SIL3 digital output module Z7138/3330/C5. Common faults:connector pin oxidation,cable aging,internal output circuit damage.Confirm system firmware before replacement.

Diagnostic

Short circuit,output abnormal or internal hardware fault triggers fault alarm;controller executes safety interlock logic.

Built‑in function

Z7138/3330/C5 outputs safety control signals to field actuators for SIS safety instrumented system emergency shutdown protection,widely used for process plant safety spare replacement.

Product Brief

Z7138/3330/C5 belongs to HIMA HIQuad X family,DIN rail mounted SIL3 8-channel digital safety output module with 3330/C5 wiring connector assembly. Verify system compatibility before ordering.Test output and diagnosis function during commissioning. ESD anti‑static protection shall be followed during installation.
