Extreme Networks X8-FM X-Pedition Fabric Module

Technical SpecificationsModel:X8-FM Brand:Extreme Networks Product Type:Hot-swappable switch fabric / crossbar module Compatible chassis:X-Pedition 8000, X-Pedition 8600 modular chassis router Function:Backplane switching fabric, inter-card data forwarding, high-speed crossbar scheduling Redundancy:Supports multiple fabric modules for fabric redundancy OS:EOS (Enterasys Operating System) Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:1.4 kg

System compatibilityX8-FM belongs to Extreme Networks X-Pedition 8000/8600 chassis router family, formerly Enterasys. It is the core fabric board for X-Pedition 8000 and 8600 chassis, responsible for high-speed data exchange between supervisor and all line cards. Multiple X8-FM modules can be installed to achieve fabric redundancy. Widely used for legacy enterprise core backbone network spare replacement.

FunctionX8-FM serves as the high-speed crossbar switching fabric of X-Pedition chassis router. It is responsible for distributing traffic between supervisor engine and all I/O line cards, providing high-bandwidth non-blocking data forwarding. It cooperates with the supervisor to maintain system switching state, monitor fabric health and report hardware faults. It supports wire-speed Layer2/Layer3 packet forwarding for all installed line cards. Used for large enterprise campus core backbone routing and traffic distribution.

InstallationHot-swappable replacement. Insert X8-FM into dedicated fabric slot of X-Pedition 8000/8600 chassis. Tighten captive screws. No external cable required for fabric module. Verify module online status and fabric health on EOS before putting into production.

InterfaceStatus LEDs, ejector latches, backplane connector for Extreme Networks X8-FM.

FeatureOriginal Extreme Networks X-Pedition series hot-swappable fabric module, high-speed non-blocking crossbar architecture, supports fabric redundancy deployment, real-time hardware fault monitoring,EOS operating system,built-in self-diagnostic function. This spare supports legacy enterprise large-scale core backbone network deployment.

DiagnosticModule not detected: check blade seating, captive screws and backplane contact. Fabric error alarm: inspect fabric module status and other installed fabric boards. Fabric redundancy sync failure: verify matching firmware across fabric modules. Over-temperature alarm: inspect chassis fan tray operation and airflow.

Product BriefX8-FM is Extreme Networks X-Pedition 8000/8600 hot-swappable switch fabric module for chassis router backplane data exchange, classic spare part for legacy enterprise core backbone network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
