Extreme Networks ST2206-0848A Gigabit PoE+ I/O Line Card

Technical SpecificationsModel:ST2206-0848A Brand:Extreme Networks Product Type:Hot-swappable I/O line card / blade Compatible chassis:S3, S4, S6, S8 S-Series modular chassis Ports:48 × 10/100/1000BASE-T RJ45 PoE+ ports PoE standard:IEEE 802.3af / 802.3at PoE+ Uplink expansion:2 × Type 2 expansion slots for optional uplink modules Architecture:S140 class distributed forwarding Minimum EOS:08.22.02.0012 Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:1.8 kg

System compatibilityST2206-0848A belongs to Extreme Networks S-Series S140 family, formerly Enterasys. It can be installed inside S3/S4/S6/S8 chassis. The two Type 2 expansion slots support additional uplink options. Widely used for enterprise campus high-density PoE access spare replacement.

FunctionST2206-0848A provides 48-port gigabit PoE+ copper access for S-series modular switches. It supplies power to wireless APs, IP cameras and IP phones. It supports wire-speed Layer2 switching, Layer3 routing, VLAN, STP, LACP, ACL, QoS and multicast. It monitors port link state, PoE power budget, module temperature and power consumption, and reports faults to chassis supervisor. Used for large-scale PoE access in enterprise campus wiring closets.

InstallationHot-swappable replacement. Insert ST2206-0848A into empty I/O slot of S3/S4/S6/S8 chassis. Tighten captive screws. Install optional Type2 uplink modules if required. Connect Cat5e/Cat6 cables to RJ45 ports. Verify module online, port status and PoE function on EOS before putting into production.

Interface48×PoE gigabit RJ45 ports,2×Type2 expansion slots,module status LEDs,PoE status indicators,ejector latches for Extreme Networks ST2206-0848A.

FeatureOriginal Extreme Networks S-Series S140 hot-swappable 48-port PoE+ gigabit line card, high-density PoE access, flexible uplink expansion, PoE power management, real-time hardware health monitoring,EOS operating system,built-in self-diagnostic function. This spare supports enterprise large-scale campus PoE access network deployment.

DiagnosticModule not detected: check card seating, captive screws and backplane contact. PoE port no power: verify PoE budget, PD detection and port admin status. Copper port link down: check Cat5e/Cat6 cable quality and port configuration. Over-temperature alarm: inspect chassis fan tray operation and airflow. Expansion module failure: check Type2 module insertion and compatibility.

Product BriefST2206-0848A is Extreme Networks S-Series S140 hot-swappable 48-port gigabit PoE+ line card for S3/S4/S6/S8 chassis, classic spare part for enterprise wiring closet high-density PoE access overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
