Extreme Networks ST4106-0248 Gigabit I/O Line Card

Technical SpecificationsModel:ST4106-0248 Brand:Extreme Networks Product Type:Hot-swappable I/O line card / blade Compatible chassis:S3, S4, S6, S8 S-Series modular chassis Ports:48 × 10/100/1000BASE-T RJ45 copper ports Architecture:S130 class distributed forwarding Minimum EOS:07.02.02.0002 Supported features:Layer2/Layer3 switching & routing, ACL, QoS, IPv4/IPv6, multicast, 802.1X authentication Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:1.72 kg

System compatibilityST4106-0248 belongs to Extreme Networks S-Series S130 family. It fits S3/S4/S6/S8 chassis slots. It is the copper counterpart to SG4101-0248 (48-port SFP S130 card). Widely used for enterprise campus wiring closet high-density gigabit copper access spare replacement.

FunctionST4106-0248 delivers 48 wire-speed gigabit copper ports for S-series modular chassis switches. It supports static and dynamic routing, VLAN, STP/RSTP/MSTP, LACP port aggregation, access control lists, quality of service, multicast and 802.1X user authentication. It continuously monitors port link status, module temperature and power consumption, and sends hardware fault alarms to the chassis supervisor. Used for high-density wired access in large enterprise campus wiring closets.

InstallationHot-swappable replacement. Insert ST4106-0248 into empty I/O slot of S3/S4/S6/S8 chassis. Tighten captive screws. Connect Cat5e/Cat6 cables to RJ45 ports. Verify module recognition and port link status on EOS before putting into production.

Interface48×10/100/1000BASE-T RJ45 copper ports, module status LEDs, ejector latches for Extreme Networks ST4106-0248.

FeatureOriginal Extreme Networks S-Series S130 hot-swappable 48-port gigabit copper line card, distributed wire-speed forwarding architecture, hardware health monitoring,EOS operating system,built-in self-diagnostic function. This spare supports legacy enterprise campus high-density copper access network deployment.

DiagnosticModule not detected: check card seating, captive screws and backplane contact. Copper port link down: verify Cat5e/Cat6 cable quality and port admin status. Port negotiation failure: inspect auto-negotiation configuration and cable. Over-temperature alarm: inspect chassis fan tray operation and airflow.

Product BriefST4106-0248 is Extreme Networks S-Series S130 hot-swappable 48-port gigabit copper line card for S3/S4/S6/S8 modular chassis, classic spare part for enterprise wiring closet high-density wired access overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
