Extreme Networks ST1206-0848-F6-S150 Gigabit PoE+ Fabric I/O Line Card

Technical SpecificationsModel:ST1206-0848-F6-S150 Brand:Extreme Networks Product Type:Hot-swappable S150 fabric I/O line card Compatible chassis:S4, S6, S8 S-Series modular chassis Ports:48 × 10/100/1000BASE-T PoE+ RJ45 ports,2 × Type2 uplink expansion slots PoE standard:IEEE 802.3af / 802.3at PoE+ Switching architecture:S150 distributed fabric forwarding Bandwidth:1280Gbps Minimum EOS:07.01.01.000X Supported features:Layer2/Layer3 switching & routing,ACL,QoS,IPv4/IPv6,multicast,802.1X Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:1.85 kg

System compatibilityST1206-0848-F6-S150 belongs to Extreme Networks S-Series S150 fabric module family, formerly Enterasys. It is designed for S4/S6/S8 chassis. The two Type2 slots support optional uplink modules for fiber or copper high-speed uplink. Widely used for enterprise campus wiring closet high-density PoE access spare replacement.

FunctionST1206-0848-F6-S150 is a high-density S150 fabric PoE+ line card for S-series modular chassis switches. It supplies PoE+ power for wireless APs,IP phones and IP cameras. It supports wire-speed Layer2 switching,Layer3 routing,VLAN,STP/RSTP/MSTP,LACP link aggregation,ACL,QoS and multicast control. It monitors port link status,PoE power consumption,module temperature and hardware faults, and sends alarms to chassis supervisor. Used for large-scale PoE access in enterprise campus wiring closets.

InstallationHot-swappable replacement. Insert ST1206-0848-F6-S150 into empty I/O slot of S4/S6/S8 chassis. Tighten captive screws. Install Type2 uplink modules if required. Connect Cat5e/Cat6 cables to RJ45 ports. Verify module online,port link and PoE function on EOS before putting into production.

Interface48×PoE gigabit RJ45 ports,2×Type2 uplink expansion slots,module status LEDs,PoE status indicators,ejector latches for Extreme Networks ST1206-0848-F6-S150.

FeatureOriginal Extreme Networks S-Series S150 hot-swappable 48-port PoE+ gigabit fabric line card,1280Gbps high bandwidth,flexible Type2 uplink expansion,PoE power budget management,real-time hardware health monitoring,EOS operating system,built-in self-diagnostic function. This spare supports legacy enterprise campus high-density PoE wired access deployment.

DiagnosticModule not detected: check card seating,captive screws and backplane contact. PoE port no power: verify PD detection,PoE budget and port admin status. Copper port link down: check Cat5e/Cat6 cable quality and auto-negotiation configuration. Uplink module not recognized: check Type2 module insertion and firmware compatibility. Over-temperature alarm: inspect chassis fan tray operation and airflow.

Product BriefST1206-0848-F6-S150 is Extreme Networks S-Series S150 hot-swappable 48-port gigabit PoE+ fabric line card with dual Type2 uplink slots for S4/S6/S8 chassis,classic spare part for enterprise wiring closet high-density PoE access network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
