Extreme Networks QSFP28 100G Pluggable Transceiver

Technical SpecificationsModel:QSFP28 Brand: Extreme Networks Product Type: Hot-swappable 100G Quad Small Form Factor Pluggable 28 Transceiver Mounting: Plug into QSFP28 port of Extreme chassis / rack switch Operating temperature: 0℃ ~ +70℃ Storage temperature: -40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Bandwidth: 103.125Gbps (4×25.78125Gbps lanes) Supported standards: 100GBASE-SR4, LR4, CWDM4, PSM4 Fiber options: multimode OM3/OM4/OM5 or single-mode OS2 Digital monitoring: DDM / DOM Weight:0.09 kg

System compatibilityQSFP28 is the 100G transceiver form factor for Extreme Networks VSP7400, VSP8400, X690, X695, X870 series switches. Supports breakout into 4×25G ports. Widely used for leaf-spine data center, high-performance computing and enterprise core network spare replacement.

FunctionQSFP28 converts four 25G electrical lanes to optical signals for 100G Ethernet transmission. It supports hardware breakout to 4 independent 25G channels. It monitors transmit optical power, receive power, module temperature and supply voltage. It triggers alarm for signal loss, over-temperature and module fault. Used to replace 100G optical transceivers in data center fabric networks.

InstallationPower off before installation. Insert QSFP28 transceiver into the switch QSFP28 slot. Connect MPO or LC fiber cables. Verify module recognition on VOSS / ExtremeXOS, check optical power and link status before putting into production.

InterfaceQSFP28 edge connector, fiber receptacle (LC or MPO), DDM digital diagnostic interface for Extreme Networks QSFP28 transceiver.

FeatureOriginal Extreme Networks QSFP28 transceiver, hot-swappable, 4-lane 25G architecture, DDM real-time monitoring, multiple fiber reach options, breakout capability, compliant with IEEE 802.3bm. This spare supports high-density data center network deployment and maintenance.

DiagnosticModule not detected: check insertion, slot status and switch firmware compatibility. Port link down: verify fiber type, optical power, cable cleanliness and port configuration. High temperature alarm: check cabinet airflow and module power consumption.

Product BriefQSFP28 is Extreme Networks 100G hot-swappable optical transceiver form factor, based on four 25G lanes, supporting SR4, LR4, CWDM4 and PSM4 variants, widely used for data center leaf-spine network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
