Extreme Networks HM-2X24GA Gigabit I/O Line Card

Technical SpecificationsModel：HM-2X24GA Brand：Network modular chassis spare Product Type: Hot-swappable gigabit I/O line card for rack mounted modular chassis switch

Front Ports:

• 48 × 10/100/1000BASE-T RJ45 gigabit copper ports, split into two groups of 24 ports (2×24)

• Port status LED for link, activity and speed indicator

• Module fault / power LED indicators

Switching & Layer Features: Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLANs Routing: Support IPv4 static routing Security: 802.1X, MAC address filtering, storm control QoS: Hardware L2-L4 classification, 8 priority queues per port

Power & Mechanical: Power Supply: Powered by chassis backplane Installation: Hot-swappable, plug into empty chassis slot Operating temperature：0℃ ~ +40℃ Weight: Approx 3.2 kg

System compatibility

HM-2X24GA is a dual 24-port gigabit line card for modular chassis network switches. It communicates with chassis main control board via backplane bus. Designed for enterprise campus and industrial chassis network port expansion.

Function

HM-2X24GA hot-swappable gigabit line card provides total 48 gigabit copper interfaces, divided into two independent 24-port groups. It connects PCs, printers and other wired terminals to the chassis core switch. Hot swap design allows replacement without powering down the whole chassis, reducing service interruption. It supports VLAN segmentation, QoS traffic scheduling and basic access security control. Widely used for large campus, factory workshop and data center access layer port expansion.

InstallationFollow ESD protection procedure. Insert HM-2X24GA module into empty chassis slot and fasten the screws. Connect RJ45 network cables to front panel ports. Verify module detection status on chassis management CLI. Configure VLAN and QoS rules. Check port link status after installation.

Interface48 GE RJ45 ports (2×24 groups),port LED indicators,fault LED,chassis backplane connector for HM-2X24GA.

FeatureOriginal HM-2X24GA gigabit line card,2 groups × 24 gigabit copper ports,hot swappable design,hardware forwarding,support VLAN,QoS and 802.1X access control. This spare line card is used for modular chassis switch gigabit port expansion and hardware replacement.

DiagnosticModule undetected: Re-seat the module, check backplane connector and chassis firmware compatibility. Port link down: Inspect cable quality, verify port speed/duplex configuration. Module fault alarm: Check temperature status and backplane power supply.

Product BriefHM-2X24GA is hot-swappable 2×24 port gigabit line card for modular chassis switch,classic spare for enterprise chassis access port expansion.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
