Extreme Networks BlackDiamond 8810 Modular Chassis Switch

Technical SpecificationsModel:BlackDiamond8810 Brand:Extreme Networks Product Type:10-slot modular core switch chassis Slots:10 total slots, supports up to 8 I/O line cards + 2 MSM management modules Switching capacity:3.8 Tbps Forwarding rate:2840 Mpps for Layer2 / Layer3 Supported OS:ExtremeXOS Redundancy:Redundant MSM,hot-swappable power supplies and fan trays Max port density:

• 768×10/100/1000BASE-T

• 400×1000BASE-SFP

• 192×10G SFP+ Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:18.5 kg

System compatibilityBlackDiamond 8810 belongs to Extreme Networks BlackDiamond 8800 series modular core switch. Compatible with 8800 series MSM modules,gigabit SFP and 10G SFP+ I/O blades,power supplies and fan trays. Widely used for enterprise core and data center aggregation spare replacement.

FunctionBlackDiamond 8810 delivers high-performance modular core switching for large enterprise and data center networks. It supports full L2/L3 routing,MLAG,STP,VRRP,ACL,QoS and IPv4/IPv6. It monitors chassis health,port status,transceiver DDM,temperature,fans and power supplies. Used to build redundant core network architecture.

InstallationMount the chassis on 19-inch rack. Install MSM control modules,line cards,fan trays and power supplies. Connect fiber/copper cables and console port for ExtremeXOS configuration. Verify chassis initialization,module online status and port connectivity before putting into production.

InterfaceFront panel module slots,status LEDs,out-of-band management port,console port,PSU and fan bays for Extreme Networks BlackDiamond 8810.

FeatureOriginal Extreme Networks BlackDiamond 8800 series 10-slot core chassis,hot-swappable all field replaceable units,1+1 MSM redundancy,high port density,ExtremeXOS OS,built-in real-time chassis health diagnostic function. This spare supports high availability core network deployment.

DiagnosticChassis fails to boot: check PSU installation and AC power input. Module not detected: verify module seating,captive screws and backplane contact. Port link down: check transceivers,fiber/copper cables and port admin status. Over-temperature alarm: inspect fan tray operation and clear dust.

Product BriefBlackDiamond8810 is Extreme Networks 10-slot modular core switch chassis with 3.8Tbps switching capacity,hot-swappable redundant components,classic spare part for large enterprise and data center core network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
