Extreme Networks AL7000MT1-E6 Chassis Fan Tray

Technical SpecificationsModel:AL7000MT1-E6 Brand: Extreme Networks Product Type: Hot-swappable Chassis Fan Tray Module Airflow: Back-to-front airflow (B-F) Compatible chassis: Extreme Networks VSP7000 series core chassis switches Redundancy: Multiple fan trays for cooling redundancy Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:1.2 kg

System compatibilityAL7000MT1-E6 is Extreme Networks cooling fan tray designed for VSP7000 core chassis switches. Multiple fan trays can be installed to provide redundant cooling. It works with AL7000MS1-E6 power supply modules. Widely used for data center core network spare replacement.

FunctionAL7000MT1-E6 provides forced cooling airflow for VSP7000 chassis, dissipating heat from fabric and I/O line cards. It reports fan speed and health status to the switch management system. It supports hot swap without shutting down the whole chassis. It triggers alarms for fan stall, speed drop and over-temperature. Used to replace faulty cooling fan trays for VSP7000 series core switch overhaul.

InstallationHot-swap replacement without powering off chassis. Insert AL7000MT1-E6 into the fan tray slot of VSP7000 chassis. Lock the latch. Verify fan status LED and fan speed readings on switch OS. Confirm normal airflow before putting into production.

InterfaceModule status LEDs, built-in fans, hot-swap ejector latch for Extreme Networks AL7000MT1-E6.

FeatureOriginal Extreme Networks VSP7000 series fan tray, hot-swappable, back-to-front airflow, redundant cooling capability, fan speed monitoring, built-in self-diagnostic function. This spare supports data center core chassis thermal management.

DiagnosticFan tray no LED: check module seating and chassis slot contact. Fan stall alarm: inspect fan rotation and clean dust buildup. Over-temperature alarm: verify fan tray installation and unobstructed air path. Cooling redundancy failure: confirm all fan trays are fully seated and operational.

Product BriefAL7000MT1-E6 is Extreme Networks hot-swappable back-to-front airflow fan tray for VSP7000 core chassis switches, provides redundant cooling, classic spare part for data center core network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
