Extreme Networks AL7000MS1-E6 Modular AC Power Supply

Technical SpecificationsModel:AL7000MS1-E6 Brand: Extreme Networks Product Type: Hot-swappable Modular AC Power Supply (Non-PoE) Rated power:200W Input: AC 100–240V Airflow: Back-to-front airflow (B-F) Output: DC system power for switch chassis Compatible chassis: Extreme Networks VSP7000 series core chassis switches Redundancy: Dual PSU slots support redundant power deployment Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:1.4 kg

System compatibilityAL7000MS1-E6 is Extreme Networks non-PoE modular power supply for VSP7000 core chassis switches. It can be installed in pairs for power redundancy. It supplies only system logic power, no PoE power output. Widely used for data center and enterprise core network spare replacement.

FunctionAL7000MS1-E6 provides stable DC system power for VSP7000 chassis. It monitors AC input voltage, DC output current, internal temperature and fan speed. It supports hot swap without shutting down the whole chassis. It triggers alarms for over-current, over-voltage, over-temperature and fan failure. Used to replace faulty system power supplies for VSP7000 series core switch overhaul.

InstallationHot-swap replacement without powering off chassis. Insert AL7000MS1-E6 into the PSU slot of VSP7000 chassis. Secure the locking latch. Verify power status LED and power health on switch OS. Confirm stable power output before putting into production.

InterfaceAC input socket, power status LEDs, built-in cooling fan, hot-swap ejector latch for Extreme Networks AL7000MS1-E6.

FeatureOriginal Extreme Networks VSP7000 series 200W AC power supply, hot-swappable, back-to-front airflow design, redundant power capable, multi-protection including over-current/over-voltage/over-temperature, built-in fan and self-diagnostic function. This spare supports data center core network chassis deployment.

DiagnosticPSU no power LED: check AC input cord and wall power supply. PSU no output: verify PSU seating and chassis slot contact. Over-temperature alarm: inspect fan rotation and chassis airflow. Redundancy failover failure: confirm both PSUs are fully seated and healthy.

Product BriefAL7000MS1-E6 is Extreme Networks 200W hot-swappable non-PoE AC modular power supply with back-to-front airflow for VSP7000 core chassis switches, supporting redundant power, classic spare part for data center core network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
