DELEM DAC-41 NC Shearing Machine Controller

Technical Specifications

Model: DAC-41 Brand: DELEM (Netherlands) Product Type: NC Controller for Hydraulic Shearing Machine Mounting: Panel mounting on shear machine cabinet Operating temperature: 0℃ ~ +45℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP20 (front panel) Power supply: 24V DC Weight: 2.3 kg

System compatibility

DAC-41 is an economical entry-level single-axis NC controller for hydraulic guillotine shearing machines. It matches incremental encoder and digital I/O modules, supports DC motor, two-speed AC motor and inverter drive for backgauge, widely used in metal fabrication workshops for controller replacement during legacy sheet metal shear overhaul.

Function

DAC-41 serves as basic backgauge positioning control unit of hydraulic shearing machine. It supports multi-step cutting position programming, controls single X axis backgauge closed-loop positioning and retract function, equipped with workpiece counting function. It has backlash compensation and power-off position memory function. It monitors machine running status and triggers alarm signals once over-travel or signal faults are detected. It is used to replace damaged controllers when the guillotine shear cannot complete backgauge positioning programming.

Installation

Cut off main power supply before installation. Reserve panel cutout on machine cabinet, mount DAC-41 and lock fixing fasteners. Connect 24V DC power, encoder cables and digital I/O terminals. Check wiring definition, upload machine parameters, perform trial cutting test before formal production.

Interface

Encoder input port, digital I/O terminals, analog speed output, LED digital status indicators for DELEM DAC-41 controller.

Feature

Original DELEM compact shear NC controller, digital LED display, membrane numeric keypad, simple multi-step position programming, built-in self-diagnostic function, compact panel housing, low power consumption. This legacy spare part supports field repair of old hydraulic guillotine shear systems.

Diagnostic

No display after power on: check 24V DC power supply and power fuse for DAC-41. Backgauge positioning error: verify encoder wiring polarity and machine parameter setting. Intermittent positioning jump: inspect encoder cable shielding and cabinet grounding condition.

Product Brief

DAC-41 is Dutch DELEM basic NC controller for hydraulic guillotine shearing machine. It executes single-axis backgauge positioning and multi-step position programming for sheet metal shearing operation, classic spare part for legacy metal fabrication machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
