DELEM DAC-360 CNC Shearing Machine Controller

Technical Specifications

Model: DAC-360 Brand: DELEM (Netherlands) Product Type: CNC Controller for Hydraulic Shearing Machine Mounting: Panel mounting on shear machine cabinet Operating temperature: 0℃ ~ +45℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP20 (front panel) Power supply: 24V DC Weight: 3.2 kg

System compatibility

DAC-360 is a dedicated CNC controller for hydraulic guillotine shearing machines. It matches hydraulic valve units, encoders and I/O modules, widely used in metal fabrication workshops for controller replacement during sheet metal shear overhaul.

Function

DAC-360 serves as the core operation control unit of hydraulic shearing machine. It stores cutting programs, automatically calculates cutting angle and blade gap based on material thickness, executes backgauge axis closed-loop positioning control. It monitors cutting force and machine running status, and triggers alarm signals once over-travel or hydraulic faults are detected. It is used to replace damaged controllers when the guillotine shear cannot complete normal cutting programming.

Installation

Cut off main power supply before installation. Reserve panel opening on machine cabinet, fix DAC-360 controller and lock mounting fasteners. Connect 24V DC power, encoder cables, hydraulic valve signal lines and digital I/O terminals. Check wiring definition, upload machine parameters, perform trial cutting test before formal production.

Interface

Encoder ports, digital I/O terminals, RS232 communication port, program backup interface, status LED indicators for DELEM DAC-360 controller.

Feature

Original DELEM CNC controller, LCD display panel, built-in material cutting parameter library, automatic blade gap calculation, backgauge servo control, simple programming workflow. This legacy spare part supports field repair of old hydraulic guillotine shear systems.

Diagnostic

No display after power on: check 24V DC power supply and power fuse for DAC-360. Backgauge positioning error: verify encoder wiring polarity and machine parameter setting. Intermittent alarm popping: inspect signal cable shielding and cabinet grounding condition.

Product Brief

DAC-360 is Dutch DELEM CNC controller for hydraulic guillotine shearing machine. It executes cutting program calculation and backgauge closed-loop control for sheet metal shearing operation, classic spare part for legacy metal fabrication machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
