DELEM DA-61 CNC Press Brake Controller

Technical Specifications

Model: DA-61 Brand: DELEM (Netherlands) Product Type: CNC Press Brake Controller Mounting: Panel mounting on bending machine cabinet Operating temperature: 0℃ ~ +45℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP20 (front panel) Power supply: 24V DC Weight: 4.5 kg

System compatibility

DA-61 is a modular 5-axis CNC controller for DELEM electro-hydraulic synchronous press brake systems. It communicates with DELEM DM series axis control modules, linear encoders and hydraulic proportional valve units, widely used in metal fabrication workshops for controller replacement during bending machine overhaul.

Function

DA-61 serves as the core operation control unit of electro-hydraulic synchronous press brake. It supports direct angle programming, stores up to 500 product programs and tool libraries, maximum 25 bends per program. It realizes Y1,Y2,X,R,V multi-axis closed-loop positioning control, automatically calculates bending tonnage, unloading distance and crowning compensation value. It integrates built-in PLC, supports manual handwheel jog function and multi-language menu. It monitors ram position and machine running status, and triggers alarm signals once over-travel or hydraulic faults are detected. It is used to replace damaged controllers when the electro-hydraulic press brake cannot complete multi-axis synchronous bending programming.

Installation

Cut off main power supply before installation. Reserve panel cutout on machine cabinet, mount DA-61 and lock fixing fasteners. Connect 24V DC power, fieldbus, encoder cables and hydraulic valve signal terminals. Check wiring definition, upload machine parameters, perform trial bending test before formal production.

Interface

Encoder input ports, digital I/O terminals, RS232 communication port, floppy disk program backup interface, status LED indicators for DELEM DA-61 controller.

Feature

Original DELEM controller, monochrome LCD display, physical keyboard operation, built-in PLC, teach-in function, 公 / 英 unit conversion, self-diagnostic system. This legacy spare part supports field repair of old DELEM electro-hydraulic synchronous press brake systems.

Diagnostic

No display after power on: check 24V DC power supply and power fuse for DA-61. Multi-axis synchronization deviation: verify encoder wiring polarity and machine parameter setting. Intermittent signal alarm: inspect cable shielding and cabinet grounding condition.

Product Brief

DA-61 is Dutch DELEM modular CNC controller for electro-hydraulic synchronous press brake. It executes angle programming and up to 5 axes closed-loop control with crowning compensation for sheet metal bending operation, classic spare part for legacy metal fabrication machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
