DELEM DA-58T CNC Press Brake Touch Controller

Technical SpecificationsModel: DA-58T Brand: DELEM (Netherlands) Product Type: 2D Graphical Touchscreen CNC Controller Mounting: Panel / swing arm mounting on bending machine cabinet Operating temperature: 0℃ ~ +45℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP54 (front panel) Power supply: 24V DC Weight: 5.2 kg

System compatibilityDA-58T belongs to DELEM DA50Touch series CNC system. It communicates with DM series axis modules via HSB high-speed bus, compatible with DM01,DM04,DM102,DM104,DM54. It supports single press brake and tandem dual bending machines, applicable for hydraulic, hybrid and electric press brakes, widely used for sheet metal machine retrofit and spare replacement.

FunctionDA-58T acts as core touch operation control unit of synchronous press brake. It supports 2D graphical workpiece programming, real-scale visualisation and bending simulation with collision detection. It automatically calculates bending sequence, sheet metal unfolded length and bending tonnage, stores abundant workpiece programs, punch & die tool libraries and material parameters. It supports multi-axis closed-loop control including Y1,Y2,X,R,V axes, automatic crowning compensation and angle sensor correction. It monitors ram position, tonnage and safety interlock signals, triggers alarm when over-travel, hydraulic fault or HSB communication dropout occurs. It is used to replace defective controllers when press brake cannot run 2D graphical bending programming.

InstallationCut off main power supply before installation. Reserve panel cutout on machine cabinet, mount DA-58T and lock fasteners. Connect 24V DC power, HSB bus cable, encoder feedback cables, digital I/O and USB terminals. Check wiring definition, upload machine parameters, complete axis homing and trial bending test before formal production.

InterfaceEthernet port, dual USB ports, service port, HSB bus interface, encoder input ports, digital I/O terminals, analog hydraulic valve output, handwheel interface, LED status indicators for DELEM DA-58T controller.

FeatureOriginal DELEM DA-58T touch controller, 15 inch 1024×768 high brightness TFT PCT touch display, aluminium front frame, supports DXF drawing import, compatible with Profile-T offline programming software, USB program backup & restore, built-in sequencer and self-diagnostic function. This spare part supports field repair and upgrade of DELEM electro-hydraulic synchronous press brake systems.

DiagnosticNo display after power on: check 24V DC power supply and power fuse for DA-58T. Bending calculation error: verify tool library, sheet metal material parameter and drawing configuration. Intermittent HSB bus alarm: inspect HSB bus cable, connector pin oxidation, shielding and cabinet grounding condition.

Product BriefDA-58T is Dutch DELEM 2D touchscreen graphical CNC controller for electro-hydraulic synchronous press brake. It performs 2D graphical programming, bending simulation and multi-axis synchronous control for sheet metal bending, classic spare part for legacy metal fabrication machine overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
