SIEMENS MOORE 16114-182 Modular Rack Assembly

Technical SpecificationsModel:16114-182 Brand:SIEMENS MOORE Product Type:Modular Rack Assembly System:APACS+ DCS System Backplane:Integrated DCS backplane bus Mounting:Cabinet rack mount Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:7.5kg Dimension:630mm195mm290mm

System compatibility16114-182 is compatible with SIEMENS MOORE APACS+ distributed control system. It serves as the main rack frame, supports installation of ACM controller, EAM, SAI, LIM communication modules and APACS rack power supply.

FunctionThis modular rack assembly provides mechanical support and backplane bus interconnection for APACS+ controller and I/O modules. The integrated backplane realizes power distribution and high-speed data communication between all inserted modules. It provides standardized slots for hot-swap module installation, builds complete DCS control node for industrial process control.

InstallationPower off the whole cabinet before installation. Fix the rack assembly inside control cabinet. Wire AC input to rack power supply. Insert power supply, controller and I/O modules into designated slots. Check backplane connection and bus communication after power on.

InterfaceIntegrated backplane bus, module slot connectors, power distribution terminals, mechanical mounting lugs.

FeatureAPACS+ standard modular rack, built-in backplane bus, multiple module slots, robust metal frame, centralized power and signal transmission. Obsolete legacy spare part, used for APACS+ DCS rack frame replacement and system reconstruction.

DiagnosticModule communication failure: inspect backplane connector contact and module slot. No power on all slots: check rack power supply and power distribution terminals. Mechanical fit issue: verify module guide rail and slot alignment.

Product BriefSIEMENS MOORE 16114-182 is APACS+ modular rack assembly, widely used in petrochemical, power and pulp & paper industries for APACS DCS control node hardware installation.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
