Siemens 39SDM048DCCBN Standard Discrete Module

Technical SpecificationsModel:39SDM048DCCBN Brand:Siemens Product Type:SDM Standard Discrete Module System:APACS+ DCS System Backplane Power Supply:24V DC Field Signal:48VDC discrete input/output Mounting:MODULRAC rack mount Operating temperature:-20℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~95%, non-condensing Weight:2.0kg Dimension:40mm260mm310mm

System compatibility39SDM048DCCBN belongs to Siemens Moore APACS+ DCS series. It fits MODULRAC rack, compatible with ACM advanced controller and APACS+ marshalled termination assemblies. It can coordinate data exchange with QUADLOG SIS safety instrumented system.

FunctionThis SDM standard discrete module handles 48VDC digital input and output signals for APACS+ DCS. It collects on/off status from field limit switches, contact feedback and digital sensors, and outputs switching commands to drive 48VDC field relays and solenoid valves. It provides per-channel circuit monitoring to detect wiring open and short faults, uploading diagnostic information to DCS controller for alarm and maintenance notification.

InstallationPower off the rack chassis before installation. Insert the module into MODULRAC rack slot and lock the latch, ensure backplane connector fully engaged. Connect ribbon cable between module and marshalled termination assembly, wire 48VDC field devices to terminal block. Configure channel parameters through APACS engineering software, verify signal reading and output action before online operation.

InterfaceBackplane bus connector, ribbon cable port for marshalling unit, front LED indicators for power, run, fault and individual channel status.

FeatureAPACS+ dedicated 48VDC discrete I/O module, integrated per-channel wiring diagnostics, electrical isolation between backplane and field circuit, hot-swappable module, Class I Division 2 hazardous area certification. Obsolete legacy spare part, used for APACS+ DCS 48V digital control loop maintenance and replacement.

DiagnosticModule no power: check rack 24V DC power supply and backplane contact. Channel signal abnormal: inspect 48VDC field wiring, field device contact and cable integrity. Channel fault alarm: check wire short circuit, loose terminal contact and field load insulation degradation.

Product BriefSiemens 39SDM048DCCBN is APACS+ SDM 48VDC standard discrete module, widely used in petrochemical, power and pulp & paper industries for DCS digital signal acquisition and field device control.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
