SEW DT71D4-BMG-TH-ES16 Asynchronous Brake Motor

Technical SpecificationsModel:DT71D4-BMG-TH-ES16 Brand:SEW Product Type:Three Phase Asynchronous AC Brake Motor Frame size:71D Pole:4 pole Rated power:0.37kW Rated speed:1380rpm Rated voltage:380V Rated current:1.24A Protection class:IP55 Insulation class:F Brake:BMG spring-applied holding brake Temperature sensor:TH thermal protection sensor Feedback:ES16 incremental encoder Cooling:Self cooling Operating temperature:-20℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibilityDT71D4-BMG-TH-ES16 belongs to SEW DT series asynchronous motor. It can be combined with SEW R,F,K,S,W series gear reducers to form gearmotors. Compatible with SEW MOVIDRIVE series inverters for closed-loop vector control. Widely used for conveyor, packaging, material handling and general automation equipment, legacy SEW drive system maintenance and spare replacement.

FunctionThis 4-pole three-phase asynchronous motor is equipped with BMG spring holding brake for shaft locking when power off. TH thermal sensor monitors winding temperature to prevent overheating damage. ES16 incremental encoder provides speed and position feedback to realize closed-loop speed regulation. It can be matched with various SEW gearboxes to reduce speed and increase torque for low-speed heavy load applications. Robust cast aluminum housing ensures stable and low-noise operation.

InstallationCut off power supply before installation. Mount motor via foot or flange installation. Align shaft carefully when assembling with gear unit or coupling, avoid excessive radial and axial load. Route power cable and encoder feedback cable separately to reduce electromagnetic interference. Wire brake circuit and TH thermal sensor to the inverter. Perform encoder offset check before commissioning.

InterfacePower terminal box, BMG brake terminals, TH temperature sensor terminals, ES16 encoder feedback connector.

FeatureSEW DT71D4-BMG-TH-ES16 compact aluminum housing brake motor,0.37kW 4-pole design. Built-in BMG safety holding brake for static shaft retention. ES16 incremental encoder supports closed-loop control for variable frequency drive. TH thermal protection protects winding from overheat damage. IP55 protection, dust-proof and splash-proof. F class insulation with good overload capability. Discontinued legacy spare part, only for DT series motor maintenance replacement. Suitable for small conveyor and light-duty packaging automation equipment requiring positioning function.

DiagnosticMotor cannot start: power missing, loose wiring or BMG brake fails to release; Overheat alarm: overloaded load, poor ventilation or damaged TH sensor; Speed feedback fault: ES16 encoder wiring failure or encoder damage; Abnormal vibration & noise: shaft misalignment, bearing wear; Brake slipping: brake lining wear or insufficient brake voltage.

Product BriefSEW DT71D4-BMG-TH-ES16 is DT series 71D frame 0.37kW 4-pole three-phase asynchronous brake motor, fitted with BMG holding brake, TH thermal sensor and ES16 incremental encoder, matched with SEW gear reducers and MOVIDRIVE inverters for closed-loop speed and positioning control.
