Sanyo Denki PQM0PA27000 Servo Amplifier

Module Feature

Sanyo Denki PQM0PA27000 belongs to PQM series high-power digital AC servo amplifier. It adopts advanced vector control algorithm, supports position, speed and torque three control modes. Equipped with RS485 serial communication interface for parameter configuration and status monitoring. Built-in multiple protection functions including overvoltage, undervoltage, overcurrent, overload, overheat and encoder error protection. Compact rack mount structure, strong anti-interference capability. Widely used for heavy-load high-torque motion axes in semiconductor equipment, machine tools and large automation production lines.

Working principle

The main power circuit converts AC input power into DC bus voltage, and the IGBT power module outputs variable frequency three-phase AC power to drive the matched servo motor. The drive receives motion commands from upper controller, collects motor encoder feedback signal, and performs high-speed closed-loop calculation to adjust output torque, speed and position. When fault conditions are detected, the drive will immediately cut off power output and trigger alarm to protect motor and peripheral mechanical equipment.

Onboard components

IGBT power module, main control CPU board, encoder signal processing circuit, RS485 communication circuit, switching power supply unit, current sampling sensor, fault detection circuit, terminal block.

LED indicators

Built-in status LED indicators, display power status, servo ready, alarm and fault codes.

Hardware self-diagnosis

Visual inspection of housing, terminals and connectors; power supply voltage test; communication line continuity check; check LED alarm codes; inspect fan operation and internal dust accumulation.

Programming software

Sanyo Denki SANMOTION setup software for servo parameter configuration, gain adjustment, status monitoring and fault diagnosis.

Electrical & Process Parameters

Model: PQM0PA27000 Input voltage: 3-phase AC200V,50/60Hz Control mode: Position / Speed / Torque Communication: RS485 Command interface: Pulse / analog command Cooling: Forced air cooling Protection: Overvoltage, undervoltage, overcurrent, overload, overheat, encoder fault Mounting: Panel mounting

Mechanical & Structure

Mounting: Panel mounting Protection class: IP20

Environmental

Operating temperature: 0℃ ~ +55℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: Sanyo Denki PQM series AC servo amplifier

System compatibility

Compatible with Sanyo Denki matched P-series servo motors to form high-power motion control system for heavy load axis positioning.

Function

PQM0PA27000 servo amplifier manufactured by Sanyo Denki. It receives motion command and drives matched servo motor to realize high precision heavy load positioning and speed regulation. Faults such as overcurrent, overheat and encoder error will trigger alarm and power cutoff. It is core drive unit for heavy-duty semiconductor and industrial automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all power supply completely. Mount the amplifier on control cabinet panel, leave enough ventilation space. Wire power cable, motor cable, encoder cable and communication cable correctly. Set servo parameters via SANMOTION software, perform trial run and positioning test before formal operation.

Interface

3-phase AC power input terminal, motor power output terminal, encoder signal connector, RS485 communication port, command signal terminal, alarm output terminal of PQM0PA27000.

Diagnostic

No power indicator: No input AC power or fuse blown. Servo not ready: Wiring error, emergency stop activated or internal hardware fault. Overcurrent alarm: Motor short circuit, cable damage or drive module damage. Overheat alarm: Poor ventilation, fan failure or continuous overload. Communication failure: Wrong RS485 wiring or mismatched communication parameters.

Product Brief

PQM0PA27000 Sanyo Denki PQM series AC servo amplifier,3-phase AC200V high power servo drive,supports position/speed/torque control,RS485 communication,panel mount,for heavy load semiconductor and industrial high torque motion axis control.
