Sanyo Denki BL900M Brushless DC Motor

Module Feature

Sanyo Denki BL900M is BL series high-efficiency DC brushless motor. It adopts permanent magnet brushless design, eliminating carbon brush wear problem for long service life. Built-in hall position sensor for speed and position feedback. Features high torque density, low heat generation and low running noise. Compact housing, excellent shock and vibration resistance. Widely applied in semiconductor automation, conveying equipment and precision industrial transmission systems.

Working principle

The matched brushless driver supplies DC power to the stator winding. The hall sensor detects rotor position in real time and sends signals to the drive. The driver commutates current electronically to drive permanent magnet rotor to rotate. Closed-loop control realizes stable speed and torque output. Internal protection circuit triggers shutdown when overcurrent or overtemperature fault occurs to protect motor assembly.

Onboard components

Permanent magnet rotor, stator winding, hall position sensor, front/rear bearing set, motor housing, shaft oil seal, power and signal terminal connector.

LED indicators

No onboard LED indicators; working status and fault codes are displayed on matched brushless driver panel.

Hardware self-diagnosis

Visual inspection of motor housing, shaft surface and connectors; winding continuity and insulation resistance test; hall sensor signal check; bearing noise inspection; feedback signal verification with matched driver.

Programming software

Sanyo Denki SANMOTION setup software for parameter configuration, speed gain tuning and fault log reading.

Electrical & Process Parameters

Model: BL900M Input voltage: DC24V Control mode: Speed / Torque Signal: Hall position feedback Cooling: Natural cooling Protection: Overcurrent, overload, overtemperature, locked rotor protection Mounting: Flange mounting

Mechanical & Structure

Mounting: Flange mounting Protection class: IP64

Environmental

Operating temperature: 0℃ ~ +40℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: Sanyo Denki BL series DC brushless motor

System compatibility

Compatible with Sanyo Denki matched BL series brushless drivers to build complete DC brushless motion control system for precision transmission.

Function

BL900M brushless motor manufactured by Sanyo Denki. It converts DC electric energy into mechanical rotary power under the control of matching driver, to realize stable speed regulation and constant torque output for automation transmission axes. Overload, wiring error or sensor damage will trigger system alarm and stop operation. It is reliable power unit for semiconductor and industrial automation equipment.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all power supply completely. Fix motor via flange mounting, align coupling properly to avoid radial and axial overload. Connect power cable and hall feedback cable to brushless driver. Set parameters via SANMOTION software, perform trial rotation and performance verification before formal operation.

Interface

Motor power terminal, hall sensor signal connector, motor housing of BL900M.

Diagnostic

Motor no rotation: No DC power supply, reversed wiring or hall sensor failure. Overload alarm: Excessive mechanical load, coupling jam or mechanical stuck. No speed feedback: Damaged signal cable or hall sensor damage. Overtemperature alarm: Continuous heavy load operation, poor heat dissipation or bearing failure. Insulation fault: Damaged stator winding or cable insulation aging.

Product Brief

BL900M Sanyo Denki BL series DC brushless motor,DC24V power supply,built-in hall position sensor,high efficiency low noise design,IP64 protection,flange mount,matched with BL series brushless drivers,for semiconductor automation and industrial precision transmission control.
