OPTIMATION OL4054RB Ruggedized 4-Slot RTU

Module Feature

OPTIMATION OL4054RB is the ruggedized coated version of OL4054 OptiLogic 4-slot modular Remote Terminal Unit base chassis. RB stands for Ruggedized Base, the mainboard PCB with protective conformal coating for resisting moisture, chemical vapor and dust in harsh cabinet environment. It supports hot-plug OptiLogic I/O modules, equipped with 10BaseT 10Mbps Ethernet supporting OptiLogic/UDP and IPX protocols, plus RS232 serial port for local configuration and HMI connection. Built-in backplane provides 2.8A@5V power supply for all installed I/O cards. NSMP means New Surplus Manufacturer Package, new spare with original factory packaging. Widely used for semiconductor wet bench and chemical fluid delivery distributed control systems with corrosive atmosphere.

Working principle: The internal backplane supplies stable power and parallel bus communication for all inserted I/O modules. It collects analog and discrete field signals from I/O cards, transmits data to host controller via Ethernet, and receives control commands to drive field actuators. The conformal coating protects base PCB from chemical vapour and humidity in wet bench cabinet. RS232 port supports firmware upgrade and local operator panel connection. Onboard components: Rugged coated main motherboard PCB, metal DIN rail housing,10BaseT Ethernet transceiver circuit, RS232 serial interface, four module slots, DC power terminal block, backplane edge connectors, front panel status LEDs

LED indicatorsPower, Ethernet link, RS232 TX/RX and rack fault LED indicators on front panel

Hardware self-diagnosis

Visual inspection, slot mechanical fit test, backplane continuity test, Ethernet link test, RS232 loopback test, module slot identification verification

Programming software

OPTIMATION OL System Builder software for network address setup, I/O module mapping, fault log reading and RTU parameter configuration

Electrical & Process Parameters

Power supply:8 ~ 30VDC Power consumption:16VA Backplane power output:2.8A @5V for I/O modules Ethernet:10BaseT Ethernet (OptiLogic/UDP, IPX) Serial port:RS232 interface Slot quantity:4 standard OptiLogic I/O slots Feature:RB rugged version with PCB conformal coating Condition:NSMP (New Surplus Manufacturer Package) Mount type:DIN rail cabinet mounting

Mechanical & Structure

Mounting:DIN rail snap-in mounting Protection class:IP20

Environmental

Operating temperature:0℃ ~ +50℃ (improved humidity and chemical vapor resistance) Ambient humidity:5~95% non-condensing Certification:CE compliant Status:OPTIMATION OptiLogic ruggedized 4-slot RTU base unit

System compatibility

Compatible with OL series I/O modules including OL2208, OL2201A, OL2111A, OL2109, OL2602, OL2252, OL0001 blank filler card; works with OP / OM series operator panels and mainstream PLC.

Function

OL4054RB rugged RTU base manufactured by OPTIMATION. It is designed for wet bench harsh environment. Conformal coating reduces risk of PCB corrosion. Poor backplane contact or wrong IP setting leads to module offline and communication interruption. NSMP version is surplus new spare with original manufacturer package. It is core modular I/O chassis for corrosive wet process automation control cabinet.

Installation

Follow lockout/tagout safety procedure before installation. Power off OptiLogic RTU rack. Mount chassis on DIN rail. Insert I/O modules into empty slots and lock latches. Wire 8-30VDC power and Ethernet cable. Configure network parameters and test all I/O channels before production startup. Install OL0001 blank filler card for unused slots.

InterfaceDC power terminal block, 10BaseT RJ45 Ethernet port, RS232 serial port, OptiLogic backplane slot connectors, power/communication/fault LED indicators on housing of OL4054RB.

Diagnostic

No Ethernet communication:IP address mismatch, cable damage or network fault. Module undetected:Damaged edge connector or poor backplane contact. Intermittent signal:Vibration causing loose module seating. Rack power alarm:Overload or loose DC input wiring.

Product Brief

OL4054RB OPTIMATION OptiLogic ruggedized 4-slot RTU remote terminal unit,8~30VDC,16VA,PCB conformal coated for harsh environment,10BaseT Ethernet & RS232,NSMP new surplus original package,for semiconductor wet bench and chemical delivery corrosive environment distributed I/O control system.
