NI PCI-1409 PCI 4-Channel High Resolution Analog Video Frame Grabber Board

Technical Specifications

Model:PCI-1409

Brand:NI

Part No:778840-01

Product type:PCI Bus High Resolution 4-Channel Monochrome Analog Video Frame Grabber

ADC:8-bit or 10-bit configurable

Video standard:RS-170,CCIR,NTSC,PAL,progressive scan and line scan cameras

Video Input:4 channels monochrome analog video,75Ω input impedance

Pixel clock:2MHz ~ 40MHz

Onboard memory:16MB SDRAM image buffer

Trigger:4 external TTL triggers,genlock synchronization

Function:ROI region capture,programmable gain & offset,hardware LUT

Synchronization:RTSI bus

Bus:PCI

Dimension:175mm106mm20mm

Weight:210g

Operating temperature:0℃ ~ +55℃

Storage temperature:-20℃ ~ +70℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

PCI-1409 belongs to NI IMAQ vision hardware platform.It works with standard PCI industrial PC,driven by NI-IMAQ and Vision Acquisition Software,supported by LabVIEW,widely used for multi monochrome analog camera capture,high-precision product inspection and line scan image acquisition in legacy machine vision systems.It is spare part for legacy automation equipment overhaul.

Function

PCI-1409 is high-performance four-channel monochrome analog frame grabber.It supports both interlaced and progressive scan cameras,also compatible with line scan sensors.Configurable 8/10-bit ADC improves grayscale resolution,16MB onboard SDRAM buffers full frame images.Genlock and RTSI realize precise synchronization with DAQ and motion control hardware.

Installation

Insert PCI-1409 into computer PCI slot and fasten bracket.Connect analog cameras to BNC or 68pin VHDCI port.Install NI-IMAQ vision driver.Take ESD protection before installation.

Interface

‑4×BNC analog video input connectors

‑68pin VHDCI multi-function I/O & trigger connector

‑RTSI synchronization bus connector

‑PCI gold finger edge connector

‑Board status indicator

Feature

PCI-1409 classic NI high-resolution multi-channel analog frame grabber board.Typical faults:BNC connector damage,ADC drift,onboard SDRAM failure.Inspect camera signal and multi-channel image capture before replacement.

Diagnostic

Fault phenomenon:no image,image noise,frame loss,sync error.Check BNC shielded cable,camera power supply,PCI slot contact,NI-IMAQ driver and genlock/RTSI configuration.

Product Brief
