NI cFP-2220 Compact FieldPoint Real-Time Dual Ethernet Controller

Technical Specifications

Model:cFP-2220

Brand:NI

Part No:cFP-2220

Product type:Compact FieldPoint Real-Time Programmable Automation Controller

Bus:Dual 10/100Base-TX Ethernet,3×RS232,1×isolated RS485

CPU:400MHz Freescale PowerPC processor

Memory:256MB DRAM,256MB non-volatile flash,CompactFlash slot,USB1.1 port

Power supply:11~30V DC,support dual redundant power input

Dimension:112mm90mm58mm

Weight:0.278kg

Interface:Dual RJ45 Ethernet port,3×RS232 D-Sub,isolated RS485,CF card slot,USB port,2DI/2DO front terminal,redundant DC power screw terminals,backplane connector for I/O modules,status LED indicators

Operating temperature:-40℃ ~ +70℃

Storage temperature:-55℃ ~ +125℃

Relative humidity:10~90% non-condensing

Certification:CE,Class I Division 2

System compatibility

cFP-2220 belongs to NI Compact FieldPoint platform.It mates with Compact FieldPoint I/O backplane and modules,runs LabVIEW Real-Time(VxWorks),supports embedded control,local data logging and multi-network & multi-serial communication,widely used in distributed industrial control and remote monitoring systems.It is spare part for legacy automation equipment overhaul.

Function

cFP-2220 is rugged real-time programmable automation controller for Compact FieldPoint backplane.It executes LabVIEW RT embedded programs independently,realizes local closed-loop control and data recording.Equipped with dual Ethernet ports for network redundancy,3 RS232 + isolated RS485 serial ports,CF card and USB slot for data storage,supports redundant power input for stable operation in harsh factory field environments.

Installation

Mount cFP-2220 on DIN rail.Connect to Compact FieldPoint backplane,wire 11~30V DC power,plug dual RJ45 network cable and serial wiring.Take ESD protection before installation.

Interface

‑Dual RJ45 10/100M Ethernet ports

‑3×RS232 D-Sub serial connectors

‑Isolated RS485 serial port

‑CompactFlash card slot

‑USB1.1 port

‑2DI/2DO front digital terminals

‑Dual redundant DC power screw terminals

‑Compact FieldPoint backplane connector

‑Status LED indicators

Feature

cFP-2220 classic NI real-time industrial controller.Typical faults:Ethernet chip failure,flash memory damage,backplane pin oxidation,serial transceiver damage.Clean backplane contacts and test firmware communication before replacement.

Diagnostic

Fault phenomenon:controller boot failure,network offline,serial communication error,I/O module communication fault.Check DC power supply,verify backplane contact,test dual Ethernet and RT firmware status.

Product Brief

cFP-2220 is NI Compact FieldPoint real-time PAC controller with dual 10/100M Ethernet,3 RS232 and isolated RS485,400MHz PowerPC CPU,CF & USB storage slot,running LabVIEW RT for standalone industrial control,DIN rail mounting,support redundant power input.Mainly used for maintenance and replacement of old industrial automation equipment.ESD protection must be followed during handling.
