MODICON CGD21-TB Servo Motor

Technical SpecificationsModel:CGD21-TB Brand:MODICON Product Type:CGD21 Series Permanent Magnet Brushless Servo Motor Motor Type:Permanent magnet brushless servo Feedback:Integrated high resolution encoder Mounting:Flange mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:3.6kg Dimension:165mm112mm142mm Protection:IP65

System compatibilityCGD21-TB belongs to MODICON CGD21 classic servo series. Compatible with supporting MODICON servo drive and motion control PLC system. Suitable for machine tool, packaging equipment, automated assembly line high precision positioning control renovation and replacement as industrial spare part.

FunctionCGD21-TB permanent magnet brushless servo motor. It converts electrical control signals into precise rotary mechanical motion, realizes closed-loop speed, torque and position control. Built-in encoder feeds back real-time position signal to servo drive to guarantee positioning accuracy. Widely used for high-precision motion control of automation equipment, serving as reliable motion spare part.

InstallationCut off servo drive power before installation. Fix CGD21-TB servo motor by flange mounting. Connect motor power cable and encoder feedback cable to servo drive. Complete servo parameter tuning, homing and load test before formal operation.

InterfaceMotor power connector,encoder feedback connector for CGD21-TB MODICON servo motor.

FeatureMODICON CGD21-TB brushless servo motor,compact structure,high torque density,stable low-speed operation,strong overload capacity,closed-loop encoder feedback,IP65 housing protection for industrial workshop environment. This discontinued legacy industrial spare part used for old MODICON motion automation system maintenance and replacement.

DiagnosticMotor no rotation: check power wiring,encoder cable connection and servo enable signal for CGD21-TB. Positioning deviation: inspect encoder fault,parameter setting and mechanical jam. Motor overheat alarm: check overload,poor ventilation and abnormal power supply. Vibration and abnormal noise: check coupling alignment,mechanical resonance and bearing wear. Encoder fault warning: inspect encoder cable damage and loose connector.

Product BriefCGD21-TB is MODICON CGD21 series permanent magnet brushless servo motor. Equipped with built-in encoder for closed loop position control,used for machine tool and automated machinery high-precision motion control,classic spare part for legacy industrial motion equipment overhaul.
