MODICON MBP-30 Communication Adapter

Technical SpecificationsModel:MBP-30 Brand:MODICON Product Type:984 Series Modbus Plus Communication Adapter Bus Type:Modbus Plus peer to peer network Backplane Power:5V DC supplied by rack backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.85kg Dimension:260mm140mm30mm Protection:IP20

System compatibilityMBP-30 belongs to MODICON 984 series communication adapter. Compatible with MODICON 984 series CPU,backplane and 800 series I/O modules. It can connect multiple MODICON PLC stations, HMI and SCADA devices through Modbus Plus network. Suitable for chemical,water treatment,metallurgy,old production line distributed PLC automation system renovation and replacement as industrial spare part.

FunctionMBP-30 Modbus Plus communication adapter. It provides Modbus Plus peer network interface for MODICON 984 PLC processor,realizes high speed bidirectional data exchange between multiple PLC nodes,upper computer monitoring and field stations. It supports network address setting,built-in communication watchdog and module diagnostic function. Widely used for industrial multi-station distributed control and data transmission, serving as reliable communication spare part.

InstallationCut off rack power before installation. Insert the MBP-30 adapter module into MODICON backplane slot and lock the card. Check gold finger contact condition. Connect Modbus Plus bus cable to module communication port. Set network station address,complete network communication test before formal operation.

InterfaceBackplane bus connector,Modbus Plus bus communication port,network and fault status LED indicators for MBP-30 MODICON communication adapter.

FeatureMODICON MBP-30 Modbus Plus adapter,standard single slot rack design,peer-to-peer network function,real-time LED status indication,built-in communication watchdog,anti-interference design for industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON 984 PLC Modbus Plus network maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for MBP-30. Network communication interruption: check bus cable,termination resistor,shielding grounding and station address setting. Intermittent data error: inspect bus cable damage and connector loose fault. LED abnormal: verify module hardware damage and backplane power supply. Fault alarm: read module diagnostic information through Modsoft programming software.

Product BriefMBP-30 is MODICON 984 series Modbus Plus communication adapter. It is used for peer network connection of MODICON 984 PLC,realizes data exchange between multiple controllers and upper monitoring equipment,classic spare part for legacy industrial automation equipment overhaul.
