MODICON 120-082-007 Remote I/O Interface Module

Technical SpecificationsModel:120-082-007 Brand:MODICON Product Type:984 Series Remote I/O Network Interface Module Backplane Power:5V DC supplied by rack backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:1.35kg Dimension:260mm140mm30mm Protection:IP20

System compatibility120-082-007 belongs to MODICON 984 series RIO remote I/O interface module. Compatible with MODICON 984 series CPU,backplane and distributed remote I/O racks. It can cooperate with 800 series digital and analog I/O modules. Suitable for chemical,water treatment,metallurgy,old production line distributed PLC automation system renovation and replacement as industrial spare part.

Function120-082-007 is dedicated remote I/O network interface adapter. It establishes bidirectional communication link between main control rack and remote I/O stations,realizes signal conversion and data transmission between PLC processor and field I/O modules. It supports rotary switch address configuration, with built-in communication watchdog and fault diagnosis function. Widely used for long-distance distributed I/O control, serving as reliable RIO communication spare part.

InstallationCut off rack power before installation. Insert the 120-082-007 module into MODICON backplane slot and lock the card. Check gold finger contact condition. Connect RIO bus cable to terminal block,set station address via rotary switch,complete communication test before formal operation.

InterfaceBackplane bus connector,remote I/O bus terminal block,network and fault status LED indicators for 120-082-007 MODICON remote I/O interface module.

FeatureMODICON 120-082-007 rack type RIO interface module,standard single slot design,rotary switch address setting,built-in communication fault detection,stable long-distance data transmission,anti-interference design for industrial workshop environment,IP20 cabinet protection. This discontinued legacy industrial spare part used for old MODICON 984 PLC distributed automation system maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for 120-082-007. Remote rack communication loss: inspect bus cable,shielding grounding and station address setting. Intermittent data error: check bus terminal resistor and cable aging. LED abnormal: verify module hardware damage and backplane power supply. Fault alarm: read module diagnostic information through Modsoft programming software.

Product Brief120-082-007 is MODICON 984 series remote I/O interface adapter. It builds communication channel between main rack and remote I/O drops for distributed process control,classic spare part for legacy MODICON 984 industrial automation equipment overhaul.
