ICM-1100 Communication Module Unit

Module Feature

ICM-1100 is an industrial multi-protocol communication module. It supports conversion between multiple mainstream industrial bus protocols, realizes data exchange between different brand PLC, DCS controllers and field sensors. Isolated circuit design protects internal circuit from surge and electromagnetic interference on industrial site. It adopts compact plug-in structure, convenient to install and maintain in control cabinet. Built-in watchdog chip ensures stable operation for long-term continuous working. Widely applied in factory automation, building control, SCADA monitoring and other industrial data interconnection scenarios.

Working principle

The module receives data frames from the field bus side, parses the communication protocol, converts data format and address mapping, then transmits the processed data to another bus port. The isolation circuit separates the field side and control side electrical signals to suppress ground loop interference. Watchdog circuit automatically resets the module when program abnormality occurs to guarantee communication recovery.

Onboard components

Main control MCU, isolated transceiver chip, bus interface terminal block, watchdog chip, status LED group, power regulation circuit, surge protection component.

LED indicators

Power LED, run LED, communication activity LED, fault alarm LED.

Hardware self-diagnosis

Power supply abnormality, bus short circuit, communication timeout, configuration error detection, records fault code and communication error statistics.

Programming software

Manufacturer PC configuration software for protocol selection, data mapping setup, communication monitoring and firmware upgrade.

Electrical & Process Parameters

Model:ICM-1100 Brand: Device type:Industrial Multi-protocol Communication Module Power supply:24VDC Communication:Multiple industrial bus protocols Isolation:Electrical isolation between channels Protection:Surge, overvoltage, undervoltage, bus short circuit

Mechanical & Structure

Mounting:DIN rail mount Protection class:IP20 Housing:Plastic flame retardant enclosure

Environmental

Operating temperature:-20℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status: Original industrial communication protocol conversion module

Installation

Follow ESD protection procedure before operation. Snap module onto DIN rail inside control cabinet. Wire power supply and bus cables to corresponding terminals. Complete protocol and data mapping configuration via PC software before commissioning.

Interface

24VDC power terminals, multi-channel bus communication terminals, configuration service port.

Diagnostic

No communication: wrong protocol parameter, bus wiring error or terminal resistor missing. Intermittent data loss: strong electromagnetic interference or unstable power supply. Module no boot: 24VDC power abnormality.

Product Brief

ICM-1100 industrial multi-protocol communication module, 24VDC power supply, channel electrical isolation, DIN rail IP20 mount, for cross-protocol data interconnection of PLC, DCS and field instruments.
