HIMA F7130 Safety I/O Carrier Module

Technical Specifications

Model:F7130

Brand:HIMA

Safety certification:SIL3,IEC61508,TÜV certified

Slot:8 slots for I/O modules

Feature:Hot-swap support,mechanical coding anti-misplug

Mounting:Plug-in subrack installation

Protection class:IP20

Power supply:24V DC

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.42kg

Certification:CE

System compatibility

Designed for HIMA H51q safety system,carries DI,AI,AO and DO I/O modules,widely used in petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function

SIL3 8-slot safety I/O carrier module.It provides backplane bus and power distribution for pluggable I/O modules.Supports hot swap replacement without system shutdown.Mechanical coding prevents wrong module insertion.Monitors rack bus communication status.

Installation

Plug into H51q rack,install I/O modules into carrier slots,configure project via SILworX software.

Interface

‑Backplane safety bus connector

‑8 slots for I/O modules

‑LED indicators for communication and fault status

Circuit feature

1oo2 fail-safe safety architecture,continuous hardware self-test,strong anti-electromagnetic interference,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature

H51q series SIL3 I/O carrier module F7130. Common faults:backplane contact failure,bus circuit damage,slot pin corrosion.Confirm rack compatibility before replacement.

Diagnostic

Bus communication failure or slot fault triggers fault alarm;controller executes safety interlock logic.

Built‑in function

F7130 provides reliable bus and power interface for I/O modules of SIS safety instrumented system emergency shutdown protection,widely used for process plant safety spare replacement.

Product Brief

F7130 belongs to HIMA H51q family,plug-in SIL3 8-slot I/O carrier backplane module for H51q safety subrack. Verify rack compatibility before ordering.Test bus communication and hot-swap function during commissioning. ESD anti‑static protection shall be followed during installation.
