HIMA F4204 Safety Digital Output Module

Technical Specifications

Model:F4204

Brand:HIMA

Safety certification:SIL3,IEC61508,TÜV certified

Channel:4-channel safety digital output

Output signal:24V DC,inductive and resistive load support

Diagnosis:Wire break,short circuit and load loop monitoring

Mounting:Plug-in subrack installation,4TE width

Protection class:IP20

Power supply:24V DC

Operating temperature:-20~+60℃

Relative humidity:5~95% non-condensing

Weight:0.42kg

Certification:CE

System compatibility

Designed for HIMA Planar-F safety system,output safety control signals for field solenoid valves and safety indicators,widely used in petrochemical,chemical plant ESD emergency shutdown and F&G fire gas protection system.

Function

SIL3 4-channel safety digital output module.It receives safety shutdown commands from Planar-F safety controller,outputs 24V DC safety signals to field devices.Each channel supports independent loop fault monitoring.When safety trip triggered,module will cut off output to realize fail-safe protection.

Installation

Plug into Planar-F rack backplane,wire field actuators to module terminals,complete hardware configuration.

Interface

‑4 channels digital output terminals

‑Backplane safety bus connector

‑LED indicators for channel status and fault

Circuit feature

1oo2 fail-safe safety architecture,periodic hardware self-test,built-in loop fault detection,strong anti-electromagnetic interference,meets SIL3 functional safety requirements for hazardous industrial environment.

Feature

Planar-F series SIL3 4-channel digital output module F4204. Common faults:output channel burnout,internal circuit damage,connector pin failure.Confirm rack compatibility before replacement.

Diagnostic

Module or wiring fault triggers channel fault alarm;controller executes safety interlock logic.

Built‑in function

F4204 outputs safety control signals for SIS safety instrumented system emergency shutdown protection,widely used for chemical and power plant safety spare replacement.

Product Brief

F4204 belongs to HIMA Planar-F family,plug-in SIL3 4-channel safety digital output module for Planar-F safety subrack. Verify rack compatibility before ordering. Test output performance and fault diagnosis function during commissioning. ESD anti‑static protection shall be followed during installation.
