Fisher 24061-668-999 Repair Kit

Technical Specifications

Model：24061-668-999 Brand：Fisher Product Type: Pneumatic actuator repair kit

Module Feature

Fisher 24061-668-999 is original factory service repair kit for Fisher diaphragm pneumatic actuator. It contains all necessary sealing consumables to rebuild actuator. It adopts oil resistant,anti-aging elastomer material for long service life. Widely applied in oil,gas,chemical and power plant control valves. Working principle: Actuator sealing renewal Onboard components: Diaphragm, O-rings, gaskets, fasteners, lubricant and instruction sheet

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, air tightness leakage test after assembly, actuator stroke test

Programming software

No dedicated software required

Mechanical & Structure

Mounting: Installed inside pneumatic diaphragm actuator Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE Status:Fisher actuator repair kit

System compatibility

Compatible with matched Fisher pneumatic diaphragm actuator and DVC series digital valve controller for industrial process control system.

Function

24061-668-999 is actuator overhaul repair kit manufactured by Fisher. It replaces aged diaphragm and sealing parts to eliminate instrument air leakage. It restores actuator response speed and valve positioning precision. It is standard spare kit for scheduled valve actuator maintenance.

Installation

Follow lockout/tagout safety procedure before installation. Cut off instrument air supply. Disassemble actuator housing, replace old diaphragm and all seals. Apply recommended lubricant and reassemble. Restore air supply and perform air tightness test and full stroke calibration.

Interface

Actuator internal fitting, fixed mounting holes, no LED indicators on 24061-668-999.

Diagnostic

Actuator air leakage: Damaged diaphragm or worn O-ring. Slow valve response: Seal friction increase or insufficient lubrication. Valve stroke drift: Internal air leakage caused by failed sealing components

Product Brief

24061-668-999 Fisher pneumatic control valve actuator repair kit,used for industrial process valve diaphragm actuator overhaul and periodic maintenance,seal spare parts kit.
