Fisher 67CF-1663-38512 Air Pressure Regulator

Technical Specifications

Model：67CF-1663-38512 Brand：Fisher Product Type: Instrument air pressure regulator

Module Feature

Fisher 67CF-1663-38512 belongs to 67CF series spring operated air pressure regulator. It reduces high instrument supply air pressure down to stable 20~100psi output for pneumatic positioners and controllers. Built-in filter and relief function. Compact structure, good anti-vibration performance. Widely used in oil,gas,chemical and power plant control valve instrument air supply loop.

Working principle: Spring and diaphragm pressure sensing for air pressure reduction Onboard components: Diaphragm assembly, valve plug, seat, pressure adjustment spring, filter element, adjusting knob, gauge port

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection, pressure setpoint test, output pressure stability test, air tightness leakage test

Programming software

No dedicated software required

Pneumatic Parameters

Medium:Dry instrument air Max inlet pressure:250psi Typical output range:0~100psi

Mechanical & Structure

Mounting: Pipe mount or direct mount on control valve actuator Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +80℃ Ambient humidity:5~95% non-condensing Certification:CE Status:Fisher 67 series air regulator

System compatibility

Compatible with Fisher valve positioners and pneumatic controllers to provide stable regulated instrument air supply.

Function

67CF-1663-38512 is instrument air regulator manufactured by Fisher. It stabilizes instrument air pressure supplied to valve positioner or pneumatic controller. Built-in filter removes particle impurities in instrument air. Overpressure relief function protects downstream pneumatic devices. It is standard accessory for control valve pneumatic loop.

Installation

Follow lockout/tagout safety procedure before installation. Isolate instrument air supply. Mount regulator on pipe or actuator bracket. Connect upstream instrument air line. Adjust output pressure by rotating set knob, test pressure stability and air tightness.

Interface

1/4"NPT inlet/outlet air ports, gauge tapping port, mounting bracket, no LED indicators on 67CF-1663-38512.

Diagnostic

Output pressure drifting: Spring fatigue or diaphragm damage. No air output: Inlet filter blockage or internal valve seat stuck. Air leakage: Diaphragm rupture or seal aging.

Product Brief

67CF-1663-38512 Fisher 67CF series instrument air pressure regulator,used for pneumatic valve positioner air supply pressure stabilization,filtering and pressure reduction,control valve pneumatic accessory.
